pH/ORP/Temp Portable Meter
VisionPlus DW-PH6810
l. Simultaneous display of pH or ORP and temperature measurements.
2. Automatic temperature compensated (ATC) pH readings.
3. 1, 2 or 3 point pH calibration, electrode efficiency display.
4. End point sensing and hold.
5. Dual buffer set selection: (4.01, 7.00, 10.01) or (4.00, 6.86, 9.18).
6. Automatic or manual temperature compensation.
7. Low battery indicator.
8. IP67 waterproof housing.
9. Rugged rubber shockproof protective boot provides extra protection in the field.
10. RoHS compliant.
Specifications | ||
Range | pH | -2.00~16.00pH |
ORP | -1999~+1999mV | |
Temperature | -10.0~120.0℃ | |
Resolution | pH | 0.01pH |
ORP | 1mV | |
Temperature | 0.1℃ | |
Accuracy | pH | ±0.1%FS±2 digits |
ORP | ±0.1%FS±2digits | |
Temperature | ±0.3℃±1 digits | |
pH Electrode Offset Recognition | ±90mV | |
pH Electrode Slope Recognition | ±30% | |
Electrode Input Impedance | >1012 Ω | |
Electrode Type | 3-in-1 pH / Reference / Temperature electrode | |
ATC | Thermistor, 10KΩ at 25℃ | |
Calibration Backup | Yes | |
Temperature Compensation | Automatic or Manual | |
Display | Large LCD | |
Power | 4 X 1.5 Volt AAA batteries | |
Auto Power Off | After 20 minutes of inactivity | |
Battery Life | >1000 hours | |
Ambient Temperature Range | From 0~50℃ | |
Case | IP-67 waterproof with rubber shockproof protective boot. | |
Weight / Dimensions ( W x D x H ) | 230 grams (Including batteries) / 75cm x 157cm x 35cm | |
Accessories | ||
6810P | pH / Temperature / Reference electrode with BNC and Mini 8 DIN connector | |
Drawell After Sales Service-----Please don't worry, our products are superior in quality, If you have any problems, please feel free to let us know, we are glad to support as below:
* Good quality firstly to avoid any defective products ;
* Operation Manuals in English ; installation & operation vedio will be provided to you as guidance ;
* We could provide Online instruction ;
* During warranty time, we can send product accessories when you need;
* Your technicians can come to our factory for training , Drawell engineers can go your place for support ( cost on your side );
* Products can be customized according to your requirements;
* Generaly the machine can use 5~10 years for average even longer if you use properly.
