2016 New Promotion Rare Earth Round Vertical Wind Turbine/ Permanent Magnet Alternator Magnet

2016 New Promotion Rare Earth Round Vertical Wind Turbine/ Permanent Magnet Alternator Magnet thumbnail-1
2016 New Promotion Rare Earth Round Vertical Wind Turbine/ Permanent Magnet Alternator Magnet photo-1
US$ 0.1 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
seatrend
Model Number:
N35-N52(M,H,SH,UH,EH)
Contact Supplier Request Quote Chat Now
Chongqing Seatrend Technology & Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name seatrend
Model Number N35-N52(M,H,SH,UH,EH)
Type Other, Permanent, Permanent
Composite Neodymium Magnet
Shape Other, Round, Disc/Round
Application Industrial Magnet

Disc Magnet Specification:

Product name:   2016 New Promotion Rare earth  round vertical wind turbine/ permanent magnet alternator magnet

1.Shape: Disc, Customized Design (Design proper magnets for clients specific requirements)

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet

2.Coating: Ni-Cu-Ni, Nickel, Zn, Gold, Silver, Copper, Epoxy, Chemical, PTFE, Parylene, Everlube, Passivation and more.



Surface Treatment Of NdFeB Magnet
Zn    Suitable for common environment
Double Nickle Layer Suitable for dew atmosphere and can be stably used for a long time
NiCuNi It has a stronger protection,adhesive ability and longer working life-span
Epoxy Suitable for severe corrosive environment

Phosphorization

Passivation

 Suitable for the situation of short-term transportation and storage
Gold  Used for high level electronic equipments and decoration

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet

3. Grades Range: N35-N52; N35M-N50M; N35H-N48H, N35SH-N45SH; N30UH-N40UH, N30EH-N38EH

                                  -The grade like N48-N52 could meet your requirements on strong power

                                  -Standard one like N35 or N40 is okay for your normal applications

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet

4.Maximum Working Temperature:

N35-N52,     80°C(176°F)

35M-50M,     100°C(212°F)

35H-48H,    120°C(248°F)

35SH-45SH,  150°C(302°F)

33UH-40UH,  180°C(356°F)

33EH-38EH,  200°C(392°F)

28AH-35AH,  220°C(428°F)

5.Tolerance:

+/-0.05mm for small dimensions,

+/-0.1mm for common specifications,

+/-0.15mm for big blocks

6. Directions of Magnetization:

a. Axially Magnetized

b. Diametrally Magnetized

c. Radial Magnetized

d. Multi-poles magnetized

e. Customzied specific requirements magnetized

Axially Magnetized                                                                         Diametrally Magnetized

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet



Technology Advantage: We have professional technical staff, the remarkable technology research center,

large scale production factory

Price Advantage:We take The centralization, scale production, reduce the cost . In the same quality products,

our price is cheaper than industry average.

Export Standard Cartons are supplied with foam well protected. We can make the packages according to

customer's request. Sea packages and air packages are both available

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet

Application:

Sintered NdFeB Magnets are widely used in many fields, such as motors, sensors, microphones, wind turbines, wind generators, VCMs in hard disk drives, printer, switchboard, loudspeakers, magnetic separation, magnetic hooks, magnetic generator, magnetic holder, magnetic chuck, common daily use, and so on.

    2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet

Packing:

 Cheapest shipping:

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet

 Our factory:



 Product Certification:

  This information is verified bycompany.



If you want to know more about vertical wind turbine/ permanent magnet alternator magnet , please don't hesitate to contact us.



Relevant product:



Disc ndfeb magnet

http://preview.china.cn/product/1957165798-221506856/widely_used_disc_plate_magnet.html



Neodymium magnet

http://preview.china.cn/product/1913371157-221506856/Strong_permanent_neodymium_magnets.html



Ring ndfeb magnet

http://preview.china.cn/product/1935572095-221506856/multi_function_high_cost_performance_large_ring_magnets.html



Block ndfeb magnet

http://preview.china.cn/product/1955848998-221506856/permanent_rare_earth_neodymium_block_magnet.html



Magnetic Ball

http://preview.china.cn/product/1956932330-221506856/multi_function_cheap_neodymium_magnets_spheres.html

2016 New Promotion Rare earth round vertical wind turbine/ permanent magnet alternator magnet
