High Quality Magnetic Work Holder for Sale

Product name: High quality magnetic work holder for sale

1.Grade: N33, N35, N38, N40, N42, N48, N50, N52 (M, H, SH, EH, UH,AH)

2.Shape: Disc, Cylinder, Block, Ring, Countersunk, Segment, Trapezoid, Irregular shapes and more. Customized Design (Design proper magnets for clients specific requirements)

3.Coating: Ni-Cu-Ni, Nickel, Zn, Gold, Silver, Copper, Epoxy, Chemical, PTFE, Parylene, Everlube, Passivation and more.

4.Maximum Working Temperature:

N35-N52,     80°C(176°F)

35M-50M,     100°C(212°F)

35H-48H,    120°C(248°F)

35SH-45SH,  150°C(302°F)

33UH-40UH,  180°C(356°F)

33EH-38EH,  200°C(392°F)

28AH-35AH,  220°C(428°F)

5.Tolerance:

+/-0.05mm for small dimensions,

+/-0.1mm for common specifications,

+/-0.15mm for big blocks

6. Directions of Magnetization:

a. Axially Magnetized

b. Diametrally Magnetized

c. Radial Magnetized

d. Multi-poles magnetized

e. Customzied specific requirements magnetized

Application

magnetic work holder are widely used in many fields, such as motors, sensors, microphones, wind turbines, wind generators, VCMs in hard disk drives, printer, switchboard, loudspeakers, magnetic separation, magnetic hooks, magnetic holder, magnetic chuck, common daily use, and so on.

Magnetic Characteristics:

Magnetization:

Technology Advantage: We have professional technical staff, the remarkable technology research center, large scale production factory

Price Advantage: We take The centralization, scale production, reduce the cost . In the same quality products, our price is cheaper than industry average.

Export Standard Cartons are supplied with foam well protected. We can make the packages according to customer's request. Sea packages and air packages are both available

Applications of magnets

Packing:
