Nylon Webbing Ribbon Cutting Machine

nylon webbing ribbon Cutting Machine

We manufacture all types of Tape Cutting Machine . High quality & low price! and provide OEM service.

Features

belt slitting machine adopts electromechanical integrating technology, it automatically adjusts the length data through the input of computer program. Automatically cutting various straps of different sizes such as braided tape, tape, plastic tube, bootlace, plastic zipper, wire, label, etc. All the data will be saved auto-matically before put off the switch. With features of high accuracy, high speed, easy to operate and stop working without materials. It's an ideal machine for increasing of efficiency, improving quality and saving labour.

Character

• Compensation:It can recover the differences caused by the material flesibility dissimilarity.
• Memory: It will save the current datas automatically before the machine is closed.
• Decimal point:special decimal point function,raised the accuacy of the product consumedly.
• Self-check:when a defect in the system,LCD curtain will display breakdown source automatically,in order to expel in the convenient check.
• Automatic power failure: 1 hour after machine stopped working, the main driving system will break power supply automatically to promise the service life of machine.
• Automatic pause: once the material uses up,will stop a current work automatically.

Operation Video

/watch?v=31qnDgU6-JU

BJ-06:

Features:

• High speed: It can cut 100~120 cut per minute. (50mm long)
• Accuracy: Cut-length is accurate cwing to a stepping motor
• Cutting type: Cutting is neat due to using a cold cutter which is durable.
• Automatic operation: It works automatically only by setting length and quantity
• Automatic stopper: It stops automatically if materials run out during operation
• Memory: Set-length, set-q'ty & set-speed are not erased even if power off & on
• Appliion: belt loop, soft tube, string, plastic zipper, elastic band, small webbing, etc.
• Freature: Heavy duty, high speed, high accuracy, designed for cutting non-adhesive materials.

Specifiions:

• Available Width: 5 ~ 100mm
• Available Length: 15 ~ 99999mm
• Speedl: 120pcs/min
• Accuracy: ± 0.1mm
• Power Supply: AC110V 60Hz / AC220V 50Hz 220W
• Measurement & Weight: 410×525×430mm 22.0Kg

We can provide:
(1) best quality products and factory price
(2)On time delievery and shortest Delivery Time
(3) Warranty:1year
(4)OEM and customized products service

Service:
(1)We guarantee each product will be checked.
(2)If there are bad products, we will promptly pay compensation to customers without any charge.

...

...
