2BQ-5 pneumatic precise seed drill

Specifications

The Precise Seeder
1. Net weight: 520kg
2.Sowing width: 2.1m
3.Row spacing: 460-640mm
4.Overall dimension(mm):1500x2300x1220

2BQ-5 Pneumatic Precise Seed Drill

2BQ-5 Pneumatic Precise Seeder, is a kind of multi-functional integral agricultural machine. It is suitable for drilling and fertilizing on the ploughed or tided field. By replacing different sprocket and seeding plate to change the distance of seed, it can precisely drill corn, soybean, sorghum, cotton and oil sunflower. Fertilizing, ditching, soil covering and press can be finished at the same time. The main features of this kind of machine are multi-function, universal operation and high efficiency.

Diving force is 60-100hp (four-wheel tractor). Row space, depth, seed distance and seeding amount can be adjusted in a large range. Thus it can satisfy the agricultural requirement of North-East, North-West and Xin Jiang dry district.

Because of the seeder is precise, please clean sundries and chioce the seed which is accord to related asking before feed.

Executing standard: JB/T10293-2001unit (precise) seeder



Specifications:

Model	Overall dimension(mm)	Net weight(Kg)	Sowing width(mm)	Sowing rows(row)	Row spacing(mm)	Working efficiency(Ha/h)
2BQ-4	1500×2300×1220	520	2100	4	460-640	0.67-0.8
2BQ-5	1500×2800×1220	565	2800	5	460-640	0.8-1.2
2BQ-6	1500×3400×1220	645	3500	6	460-640	1.2-1.33
2BQ-8	1800×6000×1500	1050	4900	8	460-640	1.33-2
