Specifications
1. major seeder manufacturer in China2. covered 30-40% domestic market
3. adopted hydraulic system to control the opener
Products detail information
Farm machinery2BFY-36 grass seeding machine is the updated version on basis of traditional draft type seeders, which is suitable for drilling small sizes of seeds such as rice, wheat, millet, etc. in large and middle sized fields..
2BFF-24 is equipped with big angle openers, which makes it possible to drill wheat in wider strip zone in Spring.
The press device can also be equipped at option for the above machine.
Specifications:
Model |
2BFY-24 |
2BFF-24 |
2BFY-36 |
Overall Dimensions(mm) |
4380×3680×1650 |
4380×3770×1650 |
6170×4030×1650 |
Net Weight(kg) |
1320 |
1430 |
1900 |
Working Width(mm) |
3600 |
3600 |
5400 |
Working Depth(mm) |
300-800 |
||
Driving Power(hp) |
50-80 |
50-80 |
65-100 |
Type of transmission |
Chain Transmission |
||
Volume of Fertilizer Box(L) |
430 |
430 |
320×2 |
Volume of Seeds Box(L) |
410 |
410 |
305×2 |
Type of Seeds Discharger |
Cast Iron Flute Wheel |
||
working efficiency(Ha/h) |
2-2.86 |
2-2.86 |
3-4.3 |
Spaces between Rows(mm) |
150(adjustable) |
||
Working Speed(km/h) |
7-10 |
||
Type of Openers |
Double-disc |
Double-Disc with Wider Spacing |
Double-disc |
Distance between front and back Openers(mm) |
260 |
490 |
260 |
Type of Clutch |
jaw(teeth) positive-contact type |
||
