Home > Products > 2BFY series hydraulic grain seeder > 24 Rows Machine to Sow Seeds
24 Rows Machine to Sow Seeds
- 1500 Set / Sets per Month
- Xingang
- T/T
Product Details
Condition: | New | Type: | Seeder | Application: | Seeding and Fertilizering |
Use: | Sowing wheat,millet,corn etc. | Place of Origin: | Hebei, China | Brand Name: | Bugu |
Model Number: | 2BFY-24 | Weight: | 1320 KG, 480 KG | Dimension(L*W*H): | 4380x3680x1650 mm |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Machine to Sow Seeds1.61 Years Factory
2.For wheat,millet,corn
3.Sowing,fertilizerig,hilling,row making
4.ISO9000
24 Rows Machine to Sow Seeds
2BFY-24 Grain Drill Fertilizer is the updated version on basis of traditional draft type seeders, which is suitable for drilling small sizes of seeds such as wheat, soybean etc. in large and middle sized fields..
2BFY-24 is equipped with big angle openers, which makes it possible to drill wheat in wider strip zone in Spring.
The press device can also be equipped at option for the above machine.
Main Technial Parameters:
Model | 2BFY-24 | 2BFF-24 | 2BFY-36 |
Overall Dimensions(mm) | 4380×3680×1650 | 4380×3770×1650 | 6170×4030×1650 |
Net Weight(kg) | 1320 | 1430 | 1900 |
Working Width(mm) | 3600 | 3600 | 5400 |
Working Depth(mm) | 300-800 | ||
Driving Power(hp) | 50-80 | 50-80 | 65-100 |
Type of transmission | Chain Transmission | ||
Volume of Fertilizer Box(L) | 430 | 430 | 320×2 |
Volume of Seeds Box(L) | 410 | 410 | 305×2 |
Type of Seeds Discharger | Cast Iron Flute Wheel | ||
working efficiency(Ha/h) | 2-2.86 | 2-2.86 | 3-4.3 |
Spaces between Rows(mm) | 150(adjustable) | ||
Working Speed(km/h) | 7-10 | ||
Type of Openers | Double-disc | Double-Disc with Wider Spacing | Double-disc |
Distance between front and back Openers(mm) | 260 | 490 | 260 |
Type of Clutch | jaw(teeth) positive-contact type |
