Coal mining ZK19 rail air drilling machine
Introduction&Application
ZK19 type rail track drilleruitable for drilling in coal minetrack laying track or splint, andcompared human hand pulling drill can greatly improve the efficacy and reduce the labor intensity of workers, and is safe and reliable, the operation is convenient and the positioning is accurate. Can also be used for metal, nonmetallic materials on drilling, reaming, tapping, etc.
Feature:ZK19 type rail track driller has the characteristics of safety explosion-proof, light weight, small size, high efficiency, simple structure, easy to use, etc.
Technical Parameters
Working pressure |
0.4-0.63MPa |
Rated speed |
165r/min |
Rated torque |
35 Nm |
The maximum torque |
>60Nm |
The idle speed |
>330 r/min |
Rated power |
0.66Kw |
Turn the gas consumption |
1.98m3/min |
Noise |
<118dB(A) |
Weight |
5.8 Kg |
Tube diameter |
16mm |
Figure Photos
