Condition New
Place of Origin Shandong, China
Brand Name Other
Model Number ND-4
Power(W) 1.42kw
Weight 16kg
Dimension(L*W*H) 1050*380*280mm
Certification ISO9001
Warranty 1 Year
After-sales Service Provided No overseas service provided
Product Description

ND-4 Internal Combustion Tamping Tool with High Quality and Low Price

Product Introduction

Internal combustion tamping picks a small road suitable for railway track maintenance machinery, mainly used for ballast track tamping homework. Its novel design, compact structure, is a kind of way rapidly up and down, stamping equipment, convenient operation is particularly suited to switch tamping homework.

Main parameter

Petrol engine model

Japanese Komatsu G4L-D

Petrol engine power

1.42kw

Working manner

Two stroke all around

Exciting force

>4.52kN

No load amplitude

>5mm

Vibration frequency

120-140Hz

Vibrating needle diameter

52mm

Accentric block rotational speed

>7000r/min

Dimention

1050*380*280mm

Total weight

13.6kg
