2016 New! Hollow Hydraulic Claw Jack Hydraulic Toe Jack
- QINGDAO
- T/T Credit Card PayPal
You May Like
-
Toe Type Claw Jack China Hydraulic Track Jack
-
5-50T High Quality Lifting Tool Portable Hydraulic Claw Jack
-
Small Hydraulic Claw Jack Toe Jack for Sale
-
Hydraulic Toe Jack/Claw Jack/hydraulic Jack High Lift CE GS TUV Approved
-
2017!! 2Ton 12 Volt Electric Car Jack Small Hydraulic Jack
-
Electric Jack/Portable Hydraulic Jack Repair Tools/Electric Jack With Wrench
Product Details
| Place of Origin | Shandong, China | Brand Name | BAFANG | |
| Model Number | MHC | Type | Hydraulic Jack | |
| Certification | ISO | Min Height | 115mm | |
| Max Height | 290mm | Capacity (Load) | 41-50T |
Product Description
2016 New! hollow Hydraulic Claw Jack hydraulic Toe Jack
1. Four different models from 5 Ton to 50 Ton
2. Low height lifting toe
3. Big and flat base provides extra stability.
On certain occasions when a heavy machine or load needs to be moved, there is very little ground clearance for machine moving skates to be placed under the machine. In such cases, you would need to lift a corner of side of the machine to lift it sufficiently to accommodate an air skate. The perfect solution would be to use hydraulic toe jacks.
Hydraulic toe jacks are designed to lift heavy machinery and other similar type loads when there is a fair amount of ground clearance. With toe-like feet, they slide under the edge of the machine to ensure stability. The lift plate is then positioned at the underside of the machine, which is then lifted clear to allow machinery moving skates to engage the load. Operated with a pump handle, lifting a heavy machine is a breeze.
Here are the technical specifications of the toe jacks we produce.
MHC Hydraulic jack
1This series products have 5 specification ,MHC-2.5RS ,MHC-5RS ,MHC-15RS ,MHC -25RS .Widely used in machinery equipment, bridge construction, railway track of installation and maintenance, and transportation of heavy loading and unloading , automobile tractor repair,ect.
Main Parameter
Model | Overall size (mm)
| Hook Mini height (mm) | Lifting height (mm) | Rated capacity (T) | Weight (kg) | |
TOP | HOOK | |||||
MHC-2.5RS | 210X140X232 | 16 | 115 | 5 | 2.5 | 11 |
MHC-5RS | 260X200X283 | 20 | 148 | 10 | 5 | 24 |
MHC-10RS | 295X220X322 | 25 | 158 | 20 | 10 | 36 |
MHC-15RS | 305X255X350 | 30 | 158 | 30 | 15 | 55 |
MHC-25RS | 340X285X350 | 50 | 158 | 50 | 25 | 75 |
