High quality KCLA-102 lithium miner lamp rack charger
Specification
The rack charger is made up of rack, power system, intelligent control charging module and special
insert setting. The rack consist rolled sheet metal, spray-paint, has nice surface and antisepticises.
The intelligent-control charging module which realized to charge with steady current and limited
voltage has the function of preventing over-charging and over-discharging, current and short circuit
protection, indicating charging state etc. The rack charger can fully automatic operate for charging
process without being from electricity wave fluctuation and load. It has high charging efficiency.
KCLA series technical parameters
Item | KCLA-102 | KCLA-60 |
AC input voltage | AC 380V or 220V | AC 380V or 220V |
AC current | 5A | 3A |
Module input voltage | DC: 6.5-12.6V | DC:6.5-12.6V |
Module output voltage (charging voltage) | DC5.0±0.05V | DC 5.0±0.05V |
Module output current (charge current) | DC1.0±0.05 | DC 1.0±0.05 |
Output ripple | 50MVP-P | 50MVP-P |
Module input under voltage protection | 6.5V | 6.5V |
Module input over-voltage protection | 12.6V | 12.6V |
Charging lights | 102 pcs | 60 pcs |
Product features
1. Each charging contact has a charging module with Such functions as data sampling, intelligent IC
Identification voltage control, conversion and shortcircuit protection. It can control the charging of Mine
lamps comprehensively.
2. The product works properly at a voltage of ac150-260 V,380V. it is characterized by stable circuit
Performance and strong antiinterference and shock Resistance. With dual LED mains and charging
Output indication, it has such advantages as short.
Charging time and high charging efficiency. In the Course of charging, the heat produced is little and
Energy loss is low, thus prolonging the service life of Mine lamps effectively.
3. Each charging contact has a built-in high-Precision sampling circuit with the function of short-circuit,
over-temperature and over-voltage Protection. The circuit makes real-time abnormality judgment
for each mine lamp during charging.
4. Charging can be conducted only after cell voltage And protection circuit are found normal by charging
Contacts when the lamp holders are fastened to Connect the loop.
