Description:
This grapple can be used to grab log, it can do single grab or a crib fetching with convenient and high work efficiency.
Features:
1.Loading capacity from 3T to 7T capacity.
2.Widely use in timber mill, sea port transportation etc.
3.Different sizes for different wheel loader.
Application Field:
Loader log grapples are widely applicable to lumber yard, sea port, transport etc.
Technical Specifications:
Model | BM0630 | BM0650 | BM0650D |
Overall length (mm) | 2300 | 2300 | 2300 |
Overall width (mm) | 1480 | 1715 | 1680 |
Overall height (mm) | 1350 | 1454 | 1600 |
Max. opening (mm) | 1500 | 1790 | 1973 |
Weight (kg) | 1023 | 1396 | 1800 |
Max. grab weight (T) | 3 | 5 | 3.5 |
Maximum hold around(mm) | 760 | 900 | 1000 |
Minimum hold around(mm) | 630 | 565 | 565 |
Pressure range(MPa) | 16-21 | 16-21 | 16-21 |
Flow range(L/min) | 120-150 | 120-150 |
|
More Detailed Photos:
Our Services:
Xuzhou HCN Attachments Manufacture Co.,Ltd. (hereinafter referred as HCN attachments) warrants that its products sold are free from defects in material and workmanship and meets HCN's current standards. The warranty period of key parts (Hydraulic Motor, Engine, Hydraulic Cylinder, Hydraulic Pump ) is 6 months or 500 working hours counting when the machine arrive to objective port. Whichever occurs first, according to the first in the calculation.
Contact Information:
Xuzhou HCN Machinery Technology Co.,Ltd.
Add: NO.28 Taoshan Rd, Jinshanqiao Xuzhou, China.
contact person: olivia
Phone:+86-18652215378
Skype: HCNOlivia
AS: HCN products are constantly updated and improved, We keep the right to change parameters and design without informing user in advance. Product appearance and color in the photo may be different from actual products, please kind prevail.
