23hp B&S engine diesel mini skid steer loader with CE

Specifications

23hp B&S engine diesel mini skid steer loader with CE
1. original B&S power
2. compact design ,light weight
3. smart and easy

Features:

1) Operating capacity: 940kg  Rated Power:23HP



2) 10 optionals you can choose: trencher,pallet fork, auger, 4 in 1



bucket,digger,breaker,snow blower,angle broom,closed broom,leveller



3) the engine you can choose: B&S engine



4) With Italian hydraulic servo system



5) With One Standard Bucket

6) With Normal Tires or Tracks

Specifications:

Model	W720
Engine type	B&S 3864
Rated power  (hp/rpm)	23/3600
noise (Db)	95
System Pressure (Mpa)	17
Working time (s)	4.27
Rated Load   (kg)	300
Bucket Capacity   (m3)	0.15
Max heavily lift  (kg)	375
Max.Travel Speed   ( km./h)	0-5.5
Solid tyres bodywork  (kg)	940
Ordinary tire body  (kg)	886
Widened tire body  (kg)	850
Solid tyres	16*6-8
Ordinary tire	5.00-8
Widened tire	KT-302 18*9.5-8  6p/TL
Herringbone engineering births	18*6.5-8
Solid tyres	4.33R-8
Ordinary tire	3.50D
Widened tire	8*6.5
Fuel tank capacity ( L )	21
Oil tank capacity  ( L )	27
Engine displacement  ( ml )	627
Bucket breakout force  (kg)	550
Tipping load (kg)	325
Length*Width*Height (mm)	1800*1150*1125
Weight (kg)	940
Track	Rubber track

 Mini skid steer loader & applications:

package details:

1step,  iron frame package  2step,  pack into the container   3step,  by sea ship or by Ro-RO ship

shipping details: New ready machinery will be deliveried within 25 days after confirming the advance payment.

Warranty:

12 months or 1500 working hours counting when the end user buys the machine from the dealer / reseller. After-sales Service Provided:     key parts (Hydraulic Motor, Hydraulic Cylinder, Hydraulic Pump ) will be provided from our company if any damage occurs in the course of operation by reason of inferior quality, bad workmanship .
