US$ 40 - 1,000
MOQ: 50 Sets
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other
Fuel:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Usage
Other
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Start
Other
Place of Origin
Chongqing, China
Brand Name
Jiasheng
Model Number
JS 152F
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Jiasheng diesel engines series
Model | 152F | 154F | 160F | 168F | 170F |
Engine type | Single cylinder,four stroke,OHC,forced air cooling | Single cylinder,four stroke,OHV 25°,forced air cooling | |||
Displacement | 98 | 87 | 118 | 196 | 216 |
Bore*stroke,mm*mm | 52*46 | 54*38 | 60*42 | 68*54 | 70*54 |
Compression ratio | 7.0:1 | 8.5:1 | |||
Max.power,kw/rpm | 1.1/3600 | 1.4/3600 | 2.2/3600 | 3.7/3600 | 4.0/3600 |
Max.torque,n.m/rpm | 2.9/2500 | 3.0/2500 | 5.7/2500 | 10/2500 | 11.1/2500 |
Fuel consumption,g/kw.h | ≤410 | ≤370 | ≤370 | ≤374 | ≤374 |
Min.stable speed,r/min | 1500±150 | ||||
Lubricating system | Lubrication by splash | ||||
Starting system | Recoil | ||||
Ignition system | CDI | ||||
Fuel designation | 90# | ||||
Fuel tank/oil capacity,L | 1.5/0.45 | 2.0/0.45 | 2.4/0.45 | 3.6/0.6 | |
N.W/G.W,kg | 9/10.5 | 10/11.5 | 14/15 | 16/17 | |
Dimension,L*W*H mm | 300*290*360 | 340*285*320 | 395*340*365 | 400*340*380 | |
20FCL Loading quantity, sets | 720 | 700 | 504 | ||
