Specifications
Standard equipment:YTO LR4108G Engine,hydraulic power shift gearbox 2F/2R,hydraulic technology 3 elements torque converter,CEMain technical parameter:
Items |
Specifications |
Items |
Specifications |
Bucket capacity |
1.1 m3 |
Min. turning radius |
4600mm |
Rated load |
2000 kg |
(outside of rear wheel) |
|
Dumping height |
2750 mm |
Steering angle |
35º each direction |
Dumping reach |
920 mm |
Min. ground clearance |
320mm |
Bucket lifting time |
5 S |
Wheel base |
2350mm |
Total cycle time |
9 S |
Tread |
1500mm |
(lifting+ dumping+ lowering ) |
|
Engine model |
LR4018G |
Max. travel speed |
25km/h |
Rated engine power |
60kW/2400rpm |
Max. breakout force |
55 kN |
Tire |
16/70-20 |
Max.drawing force |
45 kN |
Overall dimensions (L*W*H) |
5880*2060*2750mm |
Max. grade ability |
30° |
Operating weight |
6000kg |
That's one model of our wheel loader.
Besides wheel loader, we are supplier for excavator, backhoe loader, skid steer loader, bulldozer, road roller, forklift, crane, etc.
We are also one of the biggest distributor for SDLG, Changlin, XCMG, Shantui, Liugong, Komatsu spare parts.
Dear friend, more information about the price, just go ahead to contact me, I will quote our best price for you.
