We, Shandong Senxin Construction Machinery Group is the professional supplier of the heavy equipment and related spare parts.
Heavy equipment: Wheel loader, Backhoe loader, Skid steer loader, Excavator, Road roller, Bulldozer
and Motor grader.
Brand: SDLG, XCMG, SHANTUI, LIUGONG,SENX.
Self-developed SX935 3.0T Front Wheel Loader with CE
Items |
Specifications |
Items |
Specifications |
Rated capacity |
1.7m³ |
Transmission system |
Gear box separated from torque-converter |
Rated weight |
3000kg |
Torque-converter model |
YJ315x |
Operating weight |
9800kg |
Type |
Three-element, single stage |
Automatic leveling ability |
Yes |
Transmission box type |
Full power shift, countershaft type |
Static tilting load |
58.8KN |
Number of gear shift |
4 forward and 2 reverse |
Max breakout force |
120KN |
Max travel speed |
36km/h |
Max drawing force |
90KN |
Front and rear axle |
|
grade ability |
30° |
Main reducer type |
Single stage spiral reduction |
Max.dump height |
3050mm |
Final reducer |
Single stage planetary |
Max.dump reach |
1105mm |
Tire |
|
Min.ground clearance |
410mm |
Size |
17.5-25 |
Wheel base |
2600mm |
Front wheel air pressure |
343kpa |
Tread |
1800mm |
Rear wheel air pressure |
294kpa |
Height with bucket at full raise |
4870mm |
Steering system |
Fully hydraulic steering |
Lifting time |
5.5s(full load ) |
steering angle |
35°±,135°±1 respectively left/right |
Total cycle time(lifting, dumping, lowering) |
9.67s(full load) |
Min turning radius |
5160mm
|
Overall dimensions (l×w×h)mm |
6990*2420*3000 |
Hydraulic system |
|
Engine |
Yuchai engine shares co.,ltd |
Distribution valve |
DF25.2C |
Model |
YC6B125-T10 |
Gear pump |
GBGV2100 |
Type |
In line, water cooled, four stroke, direct.inject |
Brake system |
|
Rated power |
92KW |
Service brake |
Air assisted oil disc type four-wheel brake |
Rated rotation speed |
2200r/min |
Parking brake |
Soft axis, cable control |
Min oil consumption |
235g/kw.h |
Fuel tank capacity |
125L |
About Price:
The most competitive prices, different configurations with different price. We produce the construction machinery according to customer requirements.
About Payment item:
T/T 30% in advance, the balance should be paid before shipment.
Or Letter of Credit at sight.
About after-sale service:
*We supply 1500 working hours or 12 months warranty since the bill of lading date, whichever comes first.
*During the warranty period, we guarantee to provide technical support and
spare parts (caused by quality problem) freely, but the transportation cost shall be borne by the buyer.
*Out of warranty period, we will provide the main component parts for 7 years, and the other parts for 5 years, all the cost shall be be borne by the buyer.
