Customized 5HP Air Cooled Single Cylinder Vertical Gasoline Engine

Customized 5HP Air Cooled Single Cylinder Vertical Gasoline Engine thumbnail-1
Customized 5HP Air Cooled Single Cylinder Vertical Gasoline Engine photo-1
US$ 75 - 106 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Generator,water pump,lawn mower,tillers,construction&gardening machine
Fuel:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Royway Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, Generator,water pump,lawn mower,tillers,construction&gardening machine
Fuel Gasoline
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Other, Air-cooled
Start Other, Recoil start or Electric Start
Place of Origin Chongqing, China
Brand Name Coreltec
Model Number CT200
Dimension(L*W*H) 415x340x270
Weight 10.9kg
Certification ISO9001-2008,CE,EPA,CSA,SONCAP,GS,EMC
Warranty One year,spare parts
After-sales Service Provided Engineers available to service machinery overseas



Alibaba Recommended Supplier

Alibaba Golden Supplier



High quality  gasoline engine: Strong Power 17HP 192F Air Cooled Recoil/Electric Start Single Cylinder Gasoline Engine





1.Description



1)  Easy start system to meet Worlding leading startability requirement.

2)  Automatic mechanical pressure relief device: The reduction of starting resistance allows smooth and easy startup process.

3)  Mechanical speed governor: It enables an engine to rotate more steadily.

4)  Height elevatino engine oil dipstick: The application of the structure of clipping on one-quarter turn facilitates easy and quick oil adding and check.

5)  World leading Heavy_duty with lightest weight design.

6)  Canister-integrated fuel filler cap: It meets the requirements on fuel evaporation and discharge and has the function of sound effect feedback.

7.) Enlarged starting wheels: They can start easier with less effort.

8.) W&T automatic throttle control system: It is designed for wind force and temperature control without manual regulation, The startup becomes easier and faster



2.Detailed parameters of the gasoline engine



Model CT200
Horse power(hp) 5
Type Singel-cylinder,4-stroke,
Cooling Type Forced air-cooled
Bore×Stroke(mm) 70×51
Diplacement(cc) 196
Max.Torque(N.m-r/min) 10/3000
Compression Ratio 8.0:1
Dimension L×W×H(mm) 415x340x270



Customized 5HP Air Cooled Single Cylinder Vertical Gasoline Engine



5hp vertical gasoline engine



Our small air cooled vertical gasoline engine is from 3HP to 22HP.

So, if you need other types, just also let me know please, we can also provide you all kinds of engine spare parts : )



3. The Main Features

(1)  OHV leads to the lower fuel consumption and noise

(2)  Oil alert automatically shut off the engine

(3)  Electronic ignition

(4)  Speedy start, smooth operation and low vibration.

(5)  Auto decompressing makes easy starting

(6)  Different types of POT shafts meet various demands.

(7) Optional electric start available



4. Detailed Engine Introductions



 (1.) OHV Design  ( Make the engines have lower fuel consumption and noise )



(2.) Exploded drawing











(3)Different engine types ( we can produce according to your requirements, and also can use your own brand name )















 4. Delivery & Transportation Models



1.) By Express ( FedEx, UPS, DHL, TNT, EMS, etc... )

--- Advantage: Fast ( takes about 7 - 10 days in the delivery ), door to door

--- Disadvantage: A little expensive



 2.) By Air Transportation

--- Advantage: Fast ( takes about 8 - 12 days ), a little cheaper than Express.

--- Disadvantage: You need to take the goods from the airport by yourself.



 3.) By Sea ( Ocean ) Transportation

--- Advantage: Much cheaper than Express or Air transportation.

--- Disadvantage: Slow and you need to take the goods from your destination port by yourself.
