Home > Manufacturing & Processing Machinery > Agricultural Machinery > Tiller > Gasoline or Diesel Fuel Power Tiller Waking Tractor With Tiller Tractor Trailer
Gasoline or Diesel Fuel Power Tiller Waking Tractor With Tiller Tractor Trailer
US$ 240 - 300
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Farm Cultivator
Power Type:
Gasoline
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing Shanghai Shenzhe
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale and Factory Price of Gasoline Engine for Tiller WeederUS$ 100 - 300MOQ: 30 Units -
The Tractor Rototiller and Parts For SaleUS$ 225 - 300MOQ: 30 Units
-
the Small Tractor Rototiller and Parts for SaleUS$ 210 - 300MOQ: 30 Units
-
Gasoline Fule With Manual Force Snow Tiller For SaleUS$ 225 - 268MOQ: 30 Units
-
Ce/Iso Widely Used in Farm & Garden China Manufactor Low Fuel Consumption Tiller Cultivator With Power Rotary Blade Spare PartsUS$ 220 - 300MOQ: 30 Units
Condition
New
Type
Farm Cultivator
Power Type
Gasoline
Power(W)
4.8KW ~6.6KW
Certification
CE
Warranty
1 YEAR
Use
Argriculture
Place of Origin
Chongqing, China
Brand Name
Tenglong Power
Model Number
TL1WG4.0-105FQ
Weight
105KG
Dimension(L*W*H)
1000*530*800MM
After-sales Service Provided
No overseas service provided
Gasoline or Diesel Fuel Power Tiller Waking Tractor With Tiller Tractor Trailer
Product Spec.(
| Model | TL1WG4.0-105FQ |
| Engine | 170F/P,7.0HP |
| Bore*Stroke(mm) | 70*56 |
| Max Power(kw/rpm) | 5.15/3600 |
| Fuel capacity(L) | 4.5 |
| Fuel Type | Gasoline |
| Engine Oil Capacity(L) | 0.6 |
| Gearbox oil capacity(L) | 2.5 |
| Fuel consumption(g/kw.h) | ≤340 |
| Start system | Recoil start, electric start optional |
| Work width(mm) | 900-1050 |
| Work width(mm) | ≥100 |
| Gears | 2,1,0,(-1) |
| Transmission Type | Gear transmission |
| Clutch Type | Gear transmission |
| Packing size(mm) | 1000*530*800 |
| Packing Structure | Hard carton box with metal framework inside |
| N.W(kg) | 84 |
| G.W(kg) | 105 |
| Standard configuration | 32mm dry field blades(3+1 type;24pcs),400-8 tires |
| Optional configuration | Paddy field blades,30pcs/32/40pcs dry field blades,anti-tangling blades,side plate,tilling kit etc |
| Blades connections/structures | 2+1+1;2+2;3+1+1;3+2 |
More models choice
| MODEL | TL1WG4.0-105FC | TL1WG6.3-135FC | G3 | |||||||||||
| ENGINE | 178F diesel | 186F diesel | 170F/P (7.0hp) | |||||||||||
| BORE X STROKE | 78x62 | 86x70 | 70x56 | |||||||||||
| MAX POWER (Kw/rpm) | 4.4/3600 | 6.6/3600 | 5.15/3600 | |||||||||||
| FUEL CAPACITY (L) | 3.5 | 5.5 | 4.5 | |||||||||||
| FUEL TYPE | Diesel | Disel | Gasoline | |||||||||||
| ENGINE OIL CAPACITY (L) | 1.1 | 1.65 | 0.6 | |||||||||||
| GEARBOX OIL CAPACITY (L) | 2.5 | 2.5 | 0.9 | |||||||||||
| FUEL CONSUMPTION (G/Kw.h) | ≤285 | ≤282 | ≤340 | |||||||||||
| START SYSTEM | Recoil/Electric Start | Recoil/Electric Start | Recoil Start | |||||||||||
| WORK WIDTH (mm) | 1050 | 1350 | 500-700 | |||||||||||
| WORK DEPTH (mm) | ≥100 | ≥100 | ≥100 | |||||||||||
| GEARS | 2, 1, 0, -1 | 2, 1, 0, -1 | ||||||||||||
| TRANSMISSION TYPE | Gear Transmisson | Gear Transmisson | Gear Transmisson | |||||||||||
| CLUTCH | Built-in Clutch | Built-in Clutch | Built-in Clutch | |||||||||||
| PACKING SIZE (mm) | 1000x530x800 | 1020x560x840 | 870 x 440 x 780 | |||||||||||
| PACKING | Hard carton box + inner metal framework | |||||||||||||
| N.W.(kg) | 102 | 117 | 70 | |||||||||||
| G.W.(kg) | 124 | 138 | 90 | |||||||||||
| STANDARD CONFIGURATION | 32mm 3pc x 4unit dry-field blades (24pcs 3+1 type), 400-8 tire | 32mm 3pc x 4unit dry-field blades (24pcs 3+1 type), 400-8 tire | 23mm 3pc x 4unit anti-tangling blades (24pcs), 350-6 tire | |||||||||||
| OPTIONAL CONFIG. | Paddy field blades, anty-tangling blades, ditcher, side plate etc. | |||||||||||||
| BLADES CONNECTIONS | 2+1+1;2+2;3+1+1;3+2 | |||||||||||||
Tiller Process
Power Tiller Cultivator Process
Quality Control
Packaging & Shipping
1 set in a polybag, standard thicken strong carton box
Customer designed packing method is available
Company Information
Tenglong power is a general power factory located in Chongqing,China.
Over 16 years experience manufacture gasoline engine,generator,water pump,tiller/cultivator.
FAQ
Q: what is you deliver time ?
A: Within 30days after got your deposit or LC
Q: Is it all right to make customer brand name?
A: You can OEM brand name if the quantity above the MOQ.
Q: Where is your loading port?
A: Chongqing,CHINA .
Q: What are your payment term?
A: 30% deposit and balance T/T against by the copy of B/L or L/C at sight.
