Remade RPM Engine Gear Reducer
1. Product Spec.
| MODEL | TL168F/P (5.5HP) | ||||
| TYPE | 4 STROKE, 1 CYLINDER, FORCED AIR-COOLING, OHV | ||||
| DISPLACEMENT (CC) | 163 | ||||
| BORE X STROKE mm) | 68x45 | ||||
| SPEED (rpm) | 1800 ( chain belt reducer ) | ||||
| MAX POWER (HP) | 5.5 | ||||
| RATED POWER (HP) | 4.6 | ||||
| MAX TORQUE (N.m/rpm) | 8.8/2600 | ||||
| STARTING SYSTEM | RECOIL OR KEY | ||||
| IGNITION SYSTEM | Non-Contact Transistorized Magneto Ignition System | ||||
| FUEL CAPACITY (L) | 3.6 | ||||
| OIL CAPACITY(L) | 0.6 | ||||
| FUEL CONSUMPTION | ≤395 | ||||
| PACKING (LxWxH) (mm) | 400x345x380 | ||||
| N.W. (Kg) | 16 |
Detail Concern:
More Models Chose:
| MODEL | TL168F/P (5.5HP) | TL168F-1/P (6.5HP) | TL170F/P (7.0HP) | TL173F/P (8.0HP) | ||||||||||
| TYPE | 4 STROKE, 1 CYLINDER, FORCED AIR-COOLING, OHV | |||||||||||||
| DISPLACEMENT (CC) | 163 | 196 | 215 | 243 | ||||||||||
| BORE X STROKE mm) | 68x45 | 68x54 | 70 x 56 | 73x58 | ||||||||||
| SPEED (rpm) | 3600 | 3600 | 3600 | 3600 | ||||||||||
| MAX POWER (HP) | 5.5 | 6.5 | 7 | 8 | ||||||||||
| RATED POWER (HP) | 4.6 | 5.2 | 5.6 | 7.2 | ||||||||||
| MAX TORQUE (N.m/rpm) | 8.8/2600 | 10.8/2600 | 12/2600 | 16/2600 | ||||||||||
| STARTING SYSTEM | RECOIL OR KEY | RECOIL OR KEY | RECOIL OR KEY | RECOIL OR KEY | ||||||||||
| IGNITION SYSTEM | Non-Contact Transistorized Magneto Ignition System | |||||||||||||
| FUEL CAPACITY (L) | 3.6 | 3.6 | 3.6 | 6 | ||||||||||
| OIL CAPACITY(L) | 0.6 | 0.6 | 0.6 | 1.1 | ||||||||||
| FUEL CONSUMPTION | ≤395 | ≤395 | ≤395 | ≤374 | ||||||||||
| PACKING (LxWxH) (mm) | 400x345x380 | 400x345x380 | 400x345x380 | 475x450x505 | ||||||||||
| N.W. (Kg) | 16 | 17 | 18 | 23 | ||||||||||
Flow Charts:
2. Company Information.
Chongqing Tenglong Shines Electro-Mechanics Co., ltd. which was established in 1998. A professional, leading positioned the first manufacturer of gasoline engine, generator, water pump, tiller and other agricultural machineries in Chongqing, China. With more than 14 years manufacturing experience in general power industry, rigorous quality control, totally 8 procedures to ensure the quality. Outstanding technical talents and advanced technology win us a good reputation in whole China.
Powerful Engine: single cylinder 4 stroke from 2.5HP to 16HP. Recoil or key start. - 30°low temperature operation, reduce engine
Energetic generator: Single/Dual fuel powered, 100% cooper high quality electricity generated with THD less than 1.5%
Effective water pump: Self priming or centrifugal type, 1 inch to 4 inch for select
Economic tiller/cultivators: Belt or gear transmission, low cost labor saving tools for agricultural.
Trade Show & Business Negotiation:
Shipping:
More needs, plz contact me freely
