New Style Gasoline Robin Engine for Sale

Name: New Style Gasoline Robin Engine for Sale
Brand: Tenglong Power Group
SKU: 141072124
Availability: InStock

Chongqing Tenglong Shines Electro-Mechanics Co., Ltd.

US$ 50 - 80 MOQ: 50 Cartons

Key Specifications

Condition:

New

Usage:

Other, Construction; Boat; Tillers; Pump;Generator set

Fuel:

Other, Gasoline, Gasoline

Payment & Shipping

Payment Methods:

Port of Shipment:

CHONGQING

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Usage Other, Construction; Boat; Tillers; Pump;Generator set

Fuel Other, Gasoline, Gasoline

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Air-cooled

Start Other, Recoil

Place of Origin Chongqing, China

Brand Name Tenglong Power Group

Model Number TL168/P

Dimension(L*W*H) 475*450*505

Weight 13kg

Certification CE

Warranty 1 YEAR

New Style Gasoline Robin Engine for Sale

1. Factory Spec.( 4 stroke single cylinder, forced air cooling

First manufacture in Chongqing for gasoline/kerosene/LGP Engines, Generator sets, Water pumps and

Tillers /Cultivators. With more than 10 years experience in general power industry, since 1998.

2. Product spec. TL152F/P Side Valve Gasoline Engine Gold Supplier Tenglong Power Group

MODEL	TL168F/P (5.5HP)	TL168F-1/P (6.5HP)	TL170F/P (7.0HP)	TL173F/P (8.0HP)
TYPE	4 STROKE, 1 CYLINDER, FORCED AIR-COOLING, OHV
DISPLACEMENT (CC)	163	196	215	243
BORE X STROKE mm)	68x45	68x54	70 x 56	73x58
SPEED (rpm)	3600	3600	3600	3600
MAX POWER (HP)	5.5	6.5	7	8
RATED POWER (HP)	4.6	5.2	5.6	7.2
MAX TORQUE (N.m/rpm)	8.8/2600	10.8/2600	12/2600	16/2600
STARTING SYSTEM	RECOIL OR KEY	RECOIL OR KEY	RECOIL OR KEY	RECOIL OR KEY
IGNITION SYSTEM	Non-Contact Transistorized Magneto Ignition System
FUEL CAPACITY (L)	3.6	3.6	3.6	6
OIL CAPACITY(L)	0.6	0.6	0.6	1.1
FUEL CONSUMPTION	≤395	≤395	≤395	≤374
PACKING (LxWxH) (mm)	400x345x380	400x345x380	400x345x380	475x450x505
N.W. (Kg)	16	17	18	23

MODEL	TL177F/P (9.0HP)	TL182F/P (11.0HP)	TL188F/P (13.0HP)	TL190F/P (15.0HP)	TL192F/P (16HP)
TYPE	4 STROKE, 1 CYLINDER, FORCED AIR-COOLING, OHV
DISPLACEMENT (CC)	270	338	390	420	439
BORE X STROKE mm)	77 x 58	82 x 64	88 x 64	90 x 66	92 x 66
SPEED (rpm)	3600	3600	3600	3600	3600
MAX POWER (HP)	9	11	13	15	16
RATED POWER (HP)	8.2	9.5	11.5	12.5	13.5
MAX TORQUE (N.m/rpm)	18.5/2600	24/2600	26.5/2600	28/2600	30/2600
STARTING SYSTEM	RECOIL OR KEY	RECOIL OR KEY	RECOIL OR KEY	RECOIL OR KEY	RECOIL OR KEY
IGNITION SYSTEM	Non-Contact Transistorized Magneto Ignition System
FUEL CAPACITY (L)	6	6	6	6	6
OIL CAPACITY(L)	1.1	1.1	1.1	1.1	1.1
FUEL CONSUMPTION	≤374	≤374	≤374	≤370	≤370
PACKING (LxWxH) (mm)	475x450x505	475x465x515	475x465x515	475x465x515	475x465x515
N.W. (Kg)	25	31	31.5	31.5	32.5
