High Quality HZCS Series Vertical PTO Small Hammer Mill With Good Performance and Price
US$ 1 - 13,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Heilongjiang, China
Brand Name:
HZC
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Price Hot Sale HZCS Series Maize Grinding Hammer MillUS$ 1 - 1,000MOQ: 1 Set -
High Quality HZCS Series Vertical Animal Feed Crusher and Mixer Hammer Mill PriceUS$ 1 - 13,000MOQ: 1 Set
-
Professional Cheap Automatic Pouch Packing MachineUS$ 3,500 - 8,000MOQ: 1 Set
-
HZCK700S Series Vertical Ring Die Fish Feed Pellet Machinery EquimentUS$ 1 - 1,000MOQ: 1 Set
-
HZCK900M Series Wood Sawdust Pellet Press MachineUS$ 1 - 1,000MOQ: 1 Set
Condition
New
Place of Origin
Heilongjiang, China
Brand Name
HZC
Model Number
HZCS
Type
Mill Machine
Voltage
380V/400V/415V
Power(W)
22kw
Dimension(L*W*H)
2200*1000*1500mm
Weight
860 kg
Certification
ISO9001:2008
Warranty
12 Months
After-sales Service Provided
Engineers available to service machinery overseas
HZCS Series Vertical PTO Small Hammer Mill
It is applicable for agriculture,medical, chemical, metallurgical,food and architectural industry etc. It can process the hard and difficult-to-crush material including plastics and tree roots. It can also be served as the supporting equipment for use in the previous working procedure in a micro-crushing treatment.
1. Product Features:
The machine adopts a vertical crushing structure,free from the limitation of viscosity and hardness of material, and can achieve relatively good crushing effect for any material.
2. Working Principle:
The material is fed into the crushing chamber through feeding buckets. Under the impact of knife edge and its base, the rotation and fixed knives cut and crush at the same time. Due to the centrifugal action, the material will flow to the outlet automatically.
3. Technical Parameters:
| Model | HZCS22 | HZCS37 | HZCS55 | HZCS110 | HZCS160 |
| Rotating Speed of Main Shaft(rpm) | 2900 | 2900 | 2900 | 1450 | 1450 |
| Number of Hammers(pcs) | 36 | 54 | 72 | 110-160 | 160-220 |
| Weight(kg) | 860 | 1350 | 1520 | 1830 | 2300 |
| Power(kw) | 22 | 37 | 55 | 110 | 160 |
| Capacity(t/h) | 1-2 | 3-4 | 3-8 | 6-18 | 10-20 |
♦OEM Service
We can be your OEM supplier to meet your special requirements and customize your
desired models.
♦Packaging Service
Your goods will be packed properly and safely.
♦Shipping Service
We will recommend you the safest, fastest and cheapest shipping way.
♦Delivery Service
We promise to deliver your goods in shortest time.
♦Response Service
We ensure to answer your enquiry online within 12 hours.
♦After Sales Service
Any problems in the process of using will be solved by our highly skilled service engineers rapidly.
♦Warranty
One year. Free spare parts will be provided as non-artificial quality reason within 12 months.
Packing details: standard export package(carton/wooden case and pallet)
Delivery details: 15-25 days after receiving the advanced payment, depending on the ordered quantity.
