Home > Products > Biomass Energy Equipment > High Capacity Wood Pellet Cooler/Cooling Machine for sale
High Capacity Wood Pellet Cooler/Cooling Machine for sale
- 200 Set / Sets per Month
- Dalian
Product Details
Condition: | New | Place of Origin: | Heilongjiang, China | Brand Name: | HZC |
Model Number: | HZCC | Type: | Other, cooler | Voltage: | 380V |
Power(W): | 7.5-45 kw | Dimension(L*W*H): | 1800*1800*3200MM | Weight: | 1600 kg |
Certification: | ISO9001:2008/CE | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High Capacity Wood Pellet Cooler/Cooling Machine for sale
Pellet cooling machine adopts counter flow theory, namely cold air goes inside of cooler from bottom to top and hot pellets go to cooler from top to bottom.As time goes on, pellets will pile up at the cooler bottom, cold air will cool them at the bottom gradually, this process will reduce the broken rate of pellets. If cold air also goes to the cooler from top, which has the same direction as pellets flow, then hot pellets will meet with cold air suddenly, pellets will be easily broken, especially pellets surface. BY this way pellets can be cooled fully, and the broken rate is smaller than 0.2%.
1.pellet cooling machine is used to cool 2-8mm pellets. When the temperature of pellets from pellet machines is about 60-80 centigrade, after cooling the temperature is not 3-5 centigrade higher than room temperature, about 25 centigrade.
2.If we directly pack biomass pellet into bags after being pressed by the pellet machine, the pellets will be easily broken or become moldy due to hot temperature. But after cooling , no such situation happens. Especially for the pellet production line larger than 500kg/h capacity must use the pellet cooler.
3.Wood pellet cooler works with cyclone,air fan and air lock, which are used to absorb cold air and clean dust. A screener is also can be installed at the cooler bottom, which can separate powder dust from good pellets after cooling..
Features:
1.Slide type or swing type discharging mechanism;
2.Smooth and reliable running;
3.No material deposits;
5.Low energy consumption and easy operation.
Technical Parameters:
Model | HZCC1.5 | HZCC2.5 | HZCC4 | HZCC5 | HZCC6 | HZCC8 | |
Output(T/h) | 1-2 | 3-5 | 5-8 | 8-12 | 15 | 20 | |
Cooling Volume(m3) | 1.5 | 2.5 | 4 | 5 | 6 | 8 | |
Power(kw) | 1.1+7.5+0.75 | 1.5+18.5+2.2 | 2.2+22+2.2 | 2.2+30+2.2 | 3+37+2.2 | 3+45+2.2 | |
Cooling Time(minute) | Not less than 6-10min | ||||||
Cooling Temperature() | Not 3-5 centigrade higher than room temperature |
♦OEM Service
We can be your OEM supplier to meet your special requirements and customize your
desired models.
♦Packaging Service
Your goods will be packed properly and safely.
♦Shipping Service
We will recommend you the safest, fastest and cheapest shipping way.
♦Delivery Service
We promise to deliver your goods in shortest time.
♦Response Service
We ensure to answer your enquiry online within 12 hours.
♦After Sales Service
Any problems in the process of using will be solved by our highly skilled service engineers rapidly.
♦Warranty
One year. Free spare parts will be provided as non-artificial quality reason within 12 months.
Packing details: standard export package(carton/wooden case and pallet)
Delivery details: 15-25 days after receiving the advanced payment, depending on the ordered quantity.Q1: Are you a factory or trading company?
A:We are the professional manufacturing factory and we have exported our products to many countries.
Q2: Where is your factory located? How can I visit there?
A:Our factory is located in Harbin City( Heilongjiang Province, China).You can fly to Harbin Taiping International Airport and we can go to airport to pick you up directly.
Q3: How does your factory do regarding quality control?
A:Quality is priority. We always attach great importance to quality controlling from the beginning to the end. Our factory has gained CE/ISO9001:2008 authentication.
Q4: Could you send engineers to install the machine overseas?
A:Yes.We can send our engineers to help you to install the machine,but you should offer a part of the fees.
We warmly welcome customers from other parts of the world to visit us. Seeing is believing. We are very confident that after visiting our facility, you will have confidence on our products. We have the latest automatic equipments and experienced workers to ensure the stable quality and large output. We have the most sophisticated technical and engineering team to support most demanding requirement on standard and OEM products.
If you are interested in our products, please click "send" now! Pls kindly tell us the following information:
1. What's the capacity you want?
2. What's the raw material?
3. What's the size of the raw material?
4. What's the moisture content?
5. Automatic packing or manual packing needed?
6. What's your country voltage?
