Yuxiang Machinery High Yield Hot and Cold Oil Expeller With Flitering

Name: Yuxiang Machinery High Yield Hot and Cold Oil Expeller With Flitering
Brand: Yuxiang
Availability: InStock

FOB Price

US$ 1,625 - 5,000 / Set

1 Set(Min. Order)

Port Shanghai/Qingdao/Xiamen/Tianjin
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Usage	Other, press all kinds seeds into oil
Type	Other, Cold & Hot Pressing Machine, Seed Roaster	Automatic Grade	Automatic
Production Capacity	100-150kg/h	Place of Origin	Henan, China
Brand Name	Yuxiang	Model Number	6YL
Voltage	380v	Power(W)	7.5kw
Dimension(LWH)	180011001550mm	Weight	1100kg
Certification	CE ISO	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Plant direct sale Stainless Stell hot and cold oil expeller

Yuxiang machinery high yield hot and cold oil expeller with flitering

Product Description

hot and cold oil expeller is our latest development and production of hot pressing, hot pressing can be. This machine with spiral system and pressurization system of material in whole cycle, the oil pan with electric heating function, perception can keep the superiority of hot pressing.

The various parts of the hot and cold oil expeller by a screw connection, Yu Xiang mechanical press by the manufacturers of high strength bolts, solid. Good quality only if all small parts, the quality of the Yu Xiang mechanical press with diamonds. So when users choose to press what do not ask, ask the press price is not responsible for himself, the first consideration is the quality of the products, and then consider the press price is not a value.

New type hot and cold oil expeller is a new generation of low temperature screw press for hot pressed oil and design, especially suitable for pressing organic plants and high-value crops, machine pressing at low temperature, high oil yield, low residual oil cake, oil color processing of the light, good quality, rich in nutrition, to the international market standard

Parameter

Type

Voltage(v)

Screw diameter

(mm)

Screw speed

(r/min)

Main motor(kw)

Thought put(kg/h)

Whole weight(kg)

Dimension

(mm)

6YL-100

380

100

7.5

150-230

1100

1800*1200*1500

6YL-125

380

125

300-400

1500

2300*1300*2200

Raw material	oil extraction rate (%)	the cake residual rate(%)
Sesame	45-55	≤6
Peanut	43-57	≤7
Rapeseed	30-42	≤7
Sunflower seed	32-40	≤7
Soybean	12-17	≤6
Walnut	45-55	≤6

Advantage of the hot and cold oil expeller

Easy operate .This hot and cold oil expeller is matched with one controlling cabinet box to control all working process of the machines.

Low oil residual in the cake: The oil left in cake is less than 6%. The cake thickness can be adjusted once the machine stops running;

hot and cold oil expeller :Press out the cage to increase the automatic constant temperature heating device in winter low temperature time saves mill preheating time, oil start at the optimal temperature, normal work after reaching the preset temperature to stop working.

The Spare parts of the hot and cold oil expeller

If in the press Yu Xiang heavy machinery buy heavy machinery products, our company provides lifelong accessories only the cost, and to provide free technical guidance, our company in the mobile service team for at least one year free maintenance once a door for equipment. Fundamentally solve the user's worries.
