Brief introduction of Lantian brand Linseed oil press oil machine :
The main oil pressure and temperature on the rate of pressing chamber press and old oil presswith exhaust, oil line clearance is 150 silk, take the amount of slag, reducing the pressing chamber pressure, reduce the rate of oil. Our Lantian mechanical pressing chamber oil line is the gap between the 25 wires, the pressing chamber pressure, ensure the oil rate. The electronic controltechnology, to ensure the best rate of oil pressing chamber temperature, and the different needs of different oil press temperature, can timely control. Lantian machinery users to ensure that the oil rate than other oil press industry per hundred pounds of fuel oil more than 1-4 kg.
The quality of press our requirements are higher, all the appliances are used is the national famous Delixi Electric motor manufacturers, the state copper motor, gear box adopts thermalforging by Cr12 tools, screw steel, to all users to ensure the lowest yield of 400000 pounds. Lantian oil press, design better, more quality assurance.
The Main Features of Lantian Oil Press:
1.The equipment in the production process does not add any chemical additives, absolute.
2.The operation is simple, concise and convenient
3.High oil yield, low cost of the press
4.Oil pure, rich nutrition
5.The raw material choice, safe
Foreign customers to the scene
The key parts of the press
Part of raw materials
working principle
Press enter when running, pressing chamber from the hopper after dealing with oil. By pressingthe material embryo spiral constantly pushing, pressing. The blank is in the state of motionunder the press of the squeezing chamber, the pressing chamber pressure conditions, the friction between the blank and the screw, blank and pressing chamber, so that the blank materialbetween the micro friction, resulting in relative motion. On the other hand, because the rootdiameter of the screw park is gradually enlarged, the pitch is gradually reduced, so when thescrew rotation, screw and the blank that can move forward, but also can be turned outwards,and close to the screw thread surface layer with the shaft rotation. So in the squeezing chamberfor each blank particles are not the same as the speed, direction of movement, but also has the relative motion between the particles. The heat generated by friction and meet the required oil extraction process of heat, contribute to the protein thermal denaturation to blank, destruction of the colloid, increased the plastic, but also reduce the precipitate to some viscous oil, thus improving the oil press oil yield, the squeezed material the oil pressure, andfrom Park row gapand discharge gap outflow.
Technical Parameters of Automatic Hemp Oil Press:
| Model | Capacity(kg/h) | Power(kw) | weight (kg) | size (mm) |
| SYLX-100 | 150-200 | 7.5 | 1100 | 1800 x 1200 x 1500mm |
| SYLX-125 | 300-400 | 15 | 1500 | 2300 x 1300 x 2200mm |
Our service for our customers:
♥. Pre-sale service: design and manufacture machines for you as your special requirements, provide you with project, process design, and purchase programm.
♥. On-sale service: accompany with you to look around our factory, explain the manufacture process of our machines, and check the working performance of our machines.
♥. After-sale service: engineers are available to install and debugging equipments of the whole production line, besides, commissioning and training operators on site.
We have a 29 year history of the machinery manufacturers, Our specialty is worthy of your trust
If you are interested in oil press , your prompt inquiry is high appreciated.
