Lantian Brand Factory Direct Sale Oil Pressing Machine Peanut Olive Bean Oil Press Machine

Lantian Brand Factory direct sale oil pressing machine peanut olive bean oil press machine

The introduction of the machine:

1. Simple,convenient,energy saving,competitive price.

2.This oil press machine is composed of feeder, gearbox, pressing cage, screw shaft and machine stand etc

3.Final oil is high quality, good smell, and high yield rate.

4.It uses high carbon steel, which through high frequency quenching and heat-resisting, it is high hardness and strength, good abrasion resistance

5.That suit for high temperature and high pressure continous working, all this had improved the service life of the oil press for decades.

The feature of the machine :

1. Make oil from seeds and nuts. Oil is for cooking and residue cake is for animal feed or fertilizer.

2. High working efficiency! Oil press of spiral type just need process the oil plants by one time to get the maximum oil.

3. Make high quality healthy oil! Mechanical squeezing craft does not harm the nutrients in the oil. No chemical substances left.

4. Cost-Effective! Just need replace the wearing parts. The main machine can run for more than 10 years.

5. Has different models with different processing capacities, from 50kgs to 800kgs per hour per piece.

 The pictures of the machine:

working principle:

1. Transferred by the triangle belt, the electromotor drives the spiral shaft.

2. The oil plants falls into the first section of the spirals through the feeding part and being carried toward the

 end of the machine along with the rotating squeeze spirals.

3.  As the space between the squeeze spirals are getting smaller, the oil plants frictions with each other as well as the

 squeeze spirals and the squeeze loops. The pressure in the chest is becoming bigger.

4.During this process, the oil plants are smashed and big amount of heat is generated, the tissue cells are destroyed and the oil is

 separated from the oil plants and flow out from several outlets.

5. After extracted, the oil plants turns to be cake containing low oil and discharged in thin slices from the end of the machine. The whole

 oil and residue separation process is completed.

Some part of raw material of the machine :

Production flows:

our service:

♥ Before Service:

1. According to our customers special requirements, provide the most suitable project design, process design and the purchase program.

2. Guide customers to choose the best and economical plant, recover investment within short time, and site inspection.

♥ On sale service:

1. Accompany you to check the working conditions of our machines.

2. Inspect the quality of all our machines.

3. Manufacturer the equipments as the contact appears at first time after receive your deposit. Arrange the delivery timely.

♥ After sale service:

1. Send engineers to your site, help you to install and debugging devides, build plant, and training operators, at the same time pass the technology on clay

brick production to customers.

2. Guarantee of the equipments quality, maintenance, etc. Solve all the troubles for you timely during your production when receive your call oure-mails.

other machines from our factory:

Introduction of the machine:

1. The briquette machine is special for pressing the hard-briquetting coke powder and charcoal powder into briquettes which is

very popular in dometic market and overseas market.

2. Our briquette machine adopts briquetting twice for forming the powder into varienty of shapes, like oval ball shape, round ball shape,

pillow shape, egg shape and others which can meet your requirements.

3. Through about twenty-eight years' researching and developing, we have designed 4 rollers machine and hydraulic machine

 to compatible with all the powder materials.

our customers:

our factory:

1. Company information

We are a 30 years factory located in "mechanical city" Gongyi city, Henan province, China. 30 dedicated development,

we have become to a factory including design, manufacture, sale and after-sales service. Good product quality and finest after-sales

service are our intention and goal.  Our main products are different kinds briquette machines, coal briquette machine, charcoal briquette machine,

shisha charcoal briquette machine, biomass briquette machine, and other auxiliary machine crusher, dryer, feeder, conveyor machine, mixer, carbonization furnace, etc.

2.our certifications

   We can equip the line according to your practical situation. If you plan to visit China, warm welcome to visit our factory! We have plenty of video

and pictures as your reference.
