Specifications
single punch tablet pressing machine1.different moulds to choose
2.high capacity and great performance
3.good quality
TDP Single Punch Tablet Pressing
Introduction:
This machine is used to press all kinds of granular raw materials into tablets, as well as is used widely in making small lots of tablets, sugar tablets, calcium tablets and heterogeneous tablets in pharmaceutical, chemical industry, foodstuff factory and science research unit of hospital.
It is a type of mini desktop electric tablet press that is operated by electricity, as well as be waved in hand; it fixed a set of die, which is used for pressing different kinds of granular raw materials into round tablet.
The filling depth of material, pressure and thickness of tablets are adjustable.
Features:
1. This TDP1.5/5 Small Tablet Press is applicable to trial manufacturing in Lab or batch produce in small amount different kinds of tablet, sugar piece, calcium tablet and tablet of abnormal shape.
2. This TDP1.5/5 Small Tablet Press features a small desktop type press for motive and continual sheeting.
3. This TDP-1.5 /5Small Tablet Press can also be hand-operated.
4. Both filling depth of material and thickness of tablet are adjustable
Main Technical Specifications:
Type |
TDP1.5 |
TDP5 |
TDP6 |
Max Pressure(kn) |
15 |
50 |
60 |
Max Dia. of Tablet(mm) |
14 |
18 |
25 |
Max Depth of Fill(mm) |
11 |
15 |
17 |
Diameter of Up and Down Pole(mm) |
10 |
10 |
10 |
Diameter of Middle Mold(mm) |
28 |
33 |
38 |
Production Capacity(pc) |
3600 |
3600 |
3600 |
Main Morton power(kw) |
0.37 |
0.55 |
1.1/0.75 |
Net Weight (kg) |
85 |
145 |
148 |
Overall Size(mm) |
540*450*640 |
600*500*700 |
760*360*690 |
Photo show :
Details :
Mould :
Package :
