chicken farming plant feed mixer for making chicken feed pellets
>>. Animal Feed Crusher and Horizontal Feed Mixer
1. Mixer is horizontal and batch mixer,the hammer mill is small,the type can make powder feed;
2.The type of the hammer mill mixer machine have high effiency and can save the space for our feed factory.
3.The mixer body ends for double design, put an end to the two end dew material phenomenon;
4.The type of the hammer mill mixer machines equipped with grease add pipeline, overall reasonable structure, beautiful appearance, convenient operation and maintenance .
Feed Mixing Machine Photo (Carbon steel or Stainless steel)(and it can be mobile one if you want)
>>. Characteristics of Single Shaft Double Screw Horizontal Feed Mixer
1. Single shaft double screw feed mixer is an efficient and versatile blending machine for mixing of dry granules & powders homogeneously.
2.We can make stainless steel and carbon steel mixer for your choice. It has the characteristics of high efficiency, reasonable structure, compact layout, reliable performance and easy maintenance.
3. Single shaft double screw horizontal feed mixer for livestock is one of the most important operations in manufacturing of animal feeds and mixer is considered to be the heart of feed milling operation.
4.One of the main application of mixing machine animal feed is mixing feed ingredients with other micro- ingredients such as vitamins, amino acids, trace elements and other feed additives in the feed pellet mill, which is one of the main products
Feed Mixing Machine Application in Feed Pellet Production Line and Feed Powder Line
>>. Know Single Shaft Double Screw Horizontal Feed Mixer Parameter
Horizontal Mixer Model | SHJ-100 | SHJ-250 | SHJ-500 | SHJ-1000 | SHJ-2000 |
Motor Power(kw) | 3 | 5.5 | 7.5 | 18.5 | 22 |
Mix Capacity(ton) | 0.1T/Batch | 0.25T/Batch | 0.5T/Batch | 1.0T/Batch | 2.0T/Batch |
Effective Volume(m³) | 0.2 | 0.5 | 1 | 2 | 4 |
Dimension(m) | 1.4*0.6*0.75 | 1.83*0.78*1.6m | 2.45*0.82*1.85m | 2.86*1.1*1.9m | 4.5*1.45*2.7m |
Carbon Steel(mm) | 4-10mm | ||||
Mixing Time(minutes) | 3-5 minutes/Batch | ||||
Mixing Evenness (cv%) | CV ≤ 5% | ||||
Structure | "U" shape horizontal double helical ribbon mixer, Main shaft speed 25rpm | ||||
>>.Related Paddle Type Double Shaft Feed Mixer Picture(Genearl match big capacity producton line):
>>. Know Vertical Mixer Model(can be carbon steel and 304 stainless steel)
Vertical Mixer Model | SMJ-0.5T | SMJ -0.75T | SMJ -1.0T | SMJ -1.5T | SMJ -2.0T |
Motor Power(kw) | 2.2 | 3.0 | 3.0 | 3.0 | 4.0 |
Mix Capacity(ton) | 0.5T/Batch | 0.75T/Batch | 1T/Batch | 1.5T/Batch | 2T/Batch |
Weight(kg) | 150 | 175 | 200 | 250 | 300 |
Height(m) | 2.5 | 2.7 | 2.9 | 2.9 | 2.95 |
Diameter(m) | 1.0 | 1.25 | 1.25 | 1.6 | 1.8 |
Carbon Steel(mm) | 3-5mm | ||||
Mixing Time(minutes) | 10-15 minutes/Batch | ||||
Mixing Evenness (cv%) | CV ≤ 5-7% | ||||
>>.Vertical Type Poultry Feed Mixer Picture:
Factory Professional Service:
1.We devote to all-round service of all the products from shipment to maintenance.
2.Our professional service include:free training,guidance,onsite installation,and debugging.
3.After selling, we provide the warranty of two years and free technical guidance and spares parts supply.
4.If your equipments have any problems, we will help you to solve online or onsite in time.
5.Welcome oversea agents to join us expand internation market.
6.Welcome to contact us for further information!
>>. If you are interested in our mixer machne, feel free to contact Emily:
