Drum wood chipper
Hedy : Skype :machine16_2 WhatsApp : +8613165142200
Shandong Rotex Machinery Co., Ltd
1.Feature of drum wood chipper
1)The drum wood chipper is a machine cutting the tree into chips, which is widely used in the paper mill, paper pulp mill or chipboard mill. The whole set of wood chipper equipment usually including 3 parts, the log feeding structure, the wood chipper( tree chipper) and the chips discharging structure.
2) For the chips discharging structure, it usually adopted the two ways, the chips discharging tube or the discharging conveyor. The discharging tube could blow the chips to about five meters high and spray into the truck directly or the designated place. The discharging conveyor could transport the chips for a longer way to the designated place, such as warehouse.
3) The log feeding structure usually adopted two ways, the conveyor or handwork. For the big log or high capacity model chipper, it usually uses the conveyor feeding the logs into the chipper. For the small model chipper, it usually feeding the logs into chipper by hand work, which could reduce the cost of the conveyor.
2.technical parameters of drum wood chipper
Model | YGX216 | YGX218 | YGX2113 |
Feeder Size (mm) | 230*500 | 300*680 | 350*800 |
QTY of rotary knives (pcs) | 2 | 2 | 2 |
Speed of knives running(R/M) | 590 | 650 | 500 |
Max diameter feeder (mm) | 230 | 340 | 450 |
Wood chips size about (mm) | 30 | 30 | 38 |
Capacity(t/h) | 5-8 | 8-15 | 15-25 |
Power (kw) | 55+3+1.5 | 110+5.5+1.5 | 220+7.5*2+1.5 |
Weight (kg) | 4070 | 7000 | 11840 |
Outlet Size (mm) | 1800*1900*1210 | 2200*2150*1500 | 3670*2517*2050 |
3.Factory
SHANDONG ROTEX MACHINERY CO.,LTD. Employs more than 150people.
Our products include pellet machine,wood chipper,hammer mill, mixer , cooler , dryer,screener etc.
Our company has ISO9001-2000 certification,CE certification ducts cover the environmental carbon, biomass,urban and rural environment,culture & other fields.There are five main series:The biomass compression molding equipment,garbage disposal equipment for urban and rural, organic fertilizer equipment,feed equipment and environmental protection equipment.
We are an enterprise of science and technology which combined the scientific research and development ,manufacturing and training ,and international trade.Especially in the energy shortage today,starting from customers' interests,standing in the perspective of customer,consider for the customer,with our professional knowledge ,design more reasonable manufacturing flow and produce much better products .
Company adhere to the "service ,quality first,brand,reputation first"principle ,to provide customers with the best quality service.
If you have any question about the machine ,pls do not hesitate to contact me .
Hope we can established business relationship.
