Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH photo-1
Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH photo-2
Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH photo-3
Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH photo-4
Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH photo-5
Full Automatic Complete Turn-key Animal Feed Pellet Production Line More Than 10 TPH photo-6
US$ 7,650 - 7,850 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
ROTEXMASTER
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name ROTEXMASTER
Model Number YHKJ320
Type Feed Pellet Machine
Voltage 380V 50HZ 3phase
Power(W) 45kw
Dimension(L*W*H) 1100*800*1450mm
Weight 1000 kg
Certification CE ISO SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPH

Pellet making production process:

Hammer mill crushing into powder, if more than two powders, mix them, then pellet them by YHKJ horizontal ring die pellet mill, then cool them, at last pack them into small bags or ton bags.

Ring die Poultry Feed Pellet Mill  is your best choice for processing such kinds of cereals as corn, wheat, soybean and coarse fiber materials as grass, crop stalk, peanut shell and grass etc as well as some additives as molasses, vegetable oil and vitamins etc into all kinds of feed pellets for livestock, poultry and aquatic animals.

The pellets are nutritional and easy to store and transport which greatly improve the efficiency of the cultivation industry.

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPHFull Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPH

Features of Animal Feed Pellet Production Line

1). Driven by variable frequency motor, the feeder can be adjusted automatically within a certain

scope according to the production;



2). The over-load protection device work together to ensure the safety and reliability;



3). Magnetic separation and removal mechanisms are configured to prevent the iron impurities from entering

into the suppression of granulation chamber.



4). All motor are chosen by Siemens Beide Brand, save energy and reduce electricity cost.



5). The Circulating lubrication oil system is specially designed to ensure the bearings in good

 condition.



6). The ordinary conditioner, thermal insulation conditioner or double-shaft  differential  conditioner  are options according to your requirements.

The technical parameters of Animal Feed Pellet Production Line

Model

Power (Kw)

Pellet Diameter (mm)

Pellet length (mm)

Output (t/h)

YHKJ250

22

Ø2-Ø8

5-20

0.6-1.5

YHKJ300

37

Ø2-Ø8

5-20

1.5-2.1

YHKJ320

45

Ø2-Ø8

5-20

1.5-3

YHKJ350

55

Ø2-Ø8

5-20

3-5

YHKJ450

90

Ø2-Ø8

5-20

6-10

YHKJ610

160

Ø2-Ø8

5-20

8-15

Cases of Animal Feed Pellet Production Line

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPH

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPHFull Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPH

Company information:

Shandong Rotex mechinary co., ltd, an professional manufacturer in boimass fuel machinary for 8 years, with main products: boimass pellet making machine, wood pellet machine, feed pellet machine, drum wood chipper and hammer mill, rotary dryer, cooling equipment and other auxiliary equipments.

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPH

Our team

Full Automatic Complete Turn-key Animal Feed Pellet Production Line More than 10 TPH

Our Service:

Pre-sales service:

According to your raw material’s shape, size, moisture content:

1: Recommend suitable equipment,

2: Design the most suitable production line

After-sale service:

1: our technician will guide installation and degug and train your operator

2: 1 year warranty

3: life-long maintenance service
