1.Specialized in study and manufacture of wood chipper
2.ISO,CE,SGS certification
3.Can be customized
Belt conveyor with hydraulic lift wood chipper is detailed as follows:
Introduction of belt convetor with hydraulic lift wood chipper:
1.-sold in Europe,Southeast Asia etc many years
2.-wood chipper with CE
3.-make log into chips
4.-high level capacity
5.-easy operation
Main data of belt conveyor with hydraulic lift wood chipper:
| Type: | JK215 | JK216 | JK218 | JK2113 |
| Feed port size(mm) | 160*400 | 230*500 | 300*680 | 500*700 |
| Quantity of model knife(pcs) | 2 or 3 | 2 or 3 | 3 or 4 or 5 | 3 or 4 or 5 |
| Rotary speed of roller(rpm) | 590 | 590 | 650 | 500 |
| Wood chips length(mm) | 20-35 | 20-35 | 20-35 | 20-35 |
| Output capacity(T/H) | 5-8 | 8-12 | 10-20 | 25-35 |
| Max diameter of logs(mm) | 160 | 200 | 300 | 450 |
| The main motor power(KW) | 45 | 55 | 110 | 220 |
| Weight(KG) | 2990 | 4070 | 7200 | 14500 |
| Size:L*W*H(mm) | 1540*1240*1020 | 1980*1950*1250 | 2300*2150*1500 | 3850*2448*2050 |
| Diameter of roller(mm) | 500 | 600 | 800 | 1300 |
1.-Wood chipper machine, also called wood shredder, wood chipping machine, wood crusher which specially designed for round logs, square blocks ,wood staff and so on ,is used to make wood chips, wood pieces. The efficiency is much higher than the ordinary one.
2.-Operation easy , maintanence simple, life long and the noise is low. This wood chipper machien would be the best choice for factories and families which deal with wood scraps.
Other wood chipper in Jinkun:
About Zouping Jinkun Machinery Production CO.LTD:
Zouping Jinkun machinery is established in the year 1999,with occupies a total area of about 122000 square meters and gross building area of 17000 square meters.It has more than 220 employees and over 80 of are mechanical creation design and engineering technical personnels.
We have been certified by CE ISO9001 and ISO14001.Our products sell well in more than 20 provinces in China.At the same time,our products enjoy good reputation in over 10 countries and areas in Africa,South America,Eastern Europe,Southeast Asia.
