Y81 Series Hydraulic Metal Packaging

Y81 Series Hydraulic Metal Packaging thumbnail-1
Y81 Series Hydraulic Metal Packaging photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other
Packaging Type:
Other, Naked
Contact Supplier Request Quote Chat Now
Jiangsu Giant Ally Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other
Packaging Type Other, Naked
Packaging Material Metal
Automatic Grade Automatic
Driven Type Hydraulic
Power 15KW
Place of Origin Jiangsu, China
Brand Name GA
Model Number Y81

Specifications

We can supply the hydraulic baler with high quality .
Service :one year guarante and all long life maintance .

series hydraulic metal packaging can be all kinds of metal scrap (scrap, shavings, scrap steel, aluminum, copper, stainless steel scrap, scrap cars, etc.) squeezed into a rectangular, octagonal shape, the shape of a cylinder and other qualified furnace, can reduce the transportation and smelting costs, but also improve the rate of investment furnace. This series baler is mainly used in steel mills, recycling industries, as well as nonferrous metal, ferrous metal smelting industry.
Features:
1. All models use hydraulic drive, or manual or PLC control.
2. methods have turned out package package, side push package, forward packet, artificial take packs.
3. variety of models to choose from: different pressures, material box size, mass, shapes and sizes.
4. where no power supply can be powered with diesel engine

Product Specifications:



Model
Nominalforce
(kn)
Press Box size
(L×W×H)
(mm)
Bale size
(W×H)(mm)
 Bale Density(kg/m3) Productivity(kg/h) Idle Cycle Time(s) Power(kw)

Bag coming out / discharging method
Y81-63× 630 800×500×450 200×200 ≥ 2000 800~100 ≤ 75 7.5 Manual discharging
Y81-63 630 1000×600×500 200×200 ≥ 2000 900~1100 ≤ 100 7.5

Bag turming over,

Manual discharging
Y81-100 1000 1000×700×550 250×250 ≥ 2000 1200~1500 ≤ 85 11
Y81-125A 1250 1200×700×600 300×300 ≥ 2000 1200~1800 ≤ 110 15
Y81-125B 1250 1200×700×600 250×250 ≥ 2000 1200~1700 ≤ 115 15
Y81-125C 1250 1200×700×600 opposite side 250 gold octagonal ≥ 2000 1200~1700 ≤ 115 15
Y81-160 1600 1400×900×700 320×320 ≥ 2000 1500~2500 ≤ 150 22
Y81-160A 1600 1600×1000×800 340×340 ≥ 2000 2000~3500 ≤ 150 22
Y81-160B 1600 1600×1200×800 400×400 ≥ 2000 2000~4000 ≤ 150 30
Y81-200A 2000 1600×1200×800 400×400 ≥ 2000 2500~4500 ≤ 160 30 or 37
Y81-200B 2000 1800×1400×900 400×400 ≥ 2000 3000~5000 ≤ 160 30 or 37 PLC Semi-Automatic
Y81-250A 2500 2000×1400×1000 450×450 ≥ 2000 4000~6300 ≤ 160 44 or 60
Y81-250B 2500 2000×1750×1200 500×600 ≥ 2000 5000~6300 ≤ 160 60
Y81-315A 3510 2000×1400×1200 450×450 ≥ 2000 4000~6300 ≤ 160 60
Y81-315B 3510 2000×1750×1200 500×600 ≥ 2000 4000~6500 ≤ 160 60 or 66
Y81-400A 4000 2000×1600×1200 500×600 ≥ 2000 5000~7000 ≤ 160 66
Y81-400B 4000 2800×2000×1200 500×600 ≥ 2000 5000~7500 ≤ 160 110
Y81T-63 630 1000×600×500 200×200 ≥ 2000 5000~7500 ≤ 90 7.5

Bag pushing over,

Manual discharging
Y81T-100 1000 1000×700×550 250×250 ≥ 2000 8500~13000 ≤ 90 11
Y81T-100Y 1000 1000×600×500 200×(L) ≥ 2000 1000~1200 ≤ 120 11
Y81T-125A 1250 1200×700×600 300×300 ≥ 2000 16000~2300 ≤ 100 15
Y81Q-100 1000 1100×550×550 220×550 ≥ 2000 1000~1800 ≤ 85 11 forward or manual discharging
Y81Q-135 1350 1400×600×600 600×240 ≥ 2000 1500~2800 ≤ 80 22
Y81Q-160 1600 1450×600×600 600×300 ≥ 2000 2000~3000 ≤ 85 22
Y81Q-200 2000 1600×700×700 700×350 ≥ 2000 3000~3800 ≤ 85 37
