2500T Double Action Copper Extrusion Press
USD $3,000 - $60,000
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- Shanghai for Double Action copper extrusion press
- T/T
You May Like
- Professional High Precision Wide Application J23-25 cnc turret punching machines
- High Precision Wide Application J23-25 c frame punch press
- Professional High Precision Wide Application J23-25 hydraulics
- High Precision Wide Application J23-25 c frame fixed table punching machine
- Factory Sale High Precision Wide Application J23-25 construction material making machine
- High Precision Wide Application J23-25 scrap metal cutting machine for punching machine
Product Details
Condition: | New | Power Source: | Hydraulic | Place of Origin: | Jiangsu, China |
Brand Name: | Giantally, GA | Model Number: | 2500T, GA-2500T |
Product Description
Specifications
Double Action copper extrusion press:Presses are suitable for extruding metals, such as aluminum, copper, magnesium lead,etc
Double Action copper extrusion press:
Presses are suitable for extruding metals, such as aluminum, copper, magnesium lead,etc
Name | Double Action copper extrusion press | ||
Extruding pressure | KN | 25000 | |
Pressure of operation system | Mpa | 21 | |
Return force | KN | 1000 | |
Perforation stroke | mm | 900 | |
Extruding stroke | mm | 1800 | |
Dia of principal plunger piston | mm | Φ1180 | |
Extruding speed | mm/s | 0.3-13 | |
lngot vessel dimensions | mm | Φ205-Φ285 x 880 | |
Piercing force | KN | 3000 | |
Fasten strength | KN | 2000 | |
Pattern strength | KN | 2500 | |
Shearing force | KN | 1000 | |
Motor power | KW | 75 x 3 + 55 | |
Heating power | KW | 65 | |
Outer dimensions (L x W x H) | M | 12.5x4.3x4.7 | |
Height of discharging hole | mm | 1630 | |
Weight | KG | 155000 |
The picture of Double Action copper extrusion press
