Help Center8Ton Engine Timber Trailer
Related Products
Specifications
CE approval, Professional Quality, with Safty Valves and Speed Adjustable Valves, Connect to the Track hydraulic system8T Gasoline Engine Timber Trailer
Model: GTT8001
Hydraulic Supply: By track hydraulic system
Max. Lifting Capacity (at 3meter height): 600Kg
Max. Diameter of Wood grabbing: 1000mm
Max. Reach: 5300mm
Working Pressure: 20Mpa
Recommend Oil Flow: 10-35L/min
Wheels: 400/60-15.5-14PR or at your request.
Max. Trailer loading: 8000Kg
Length: 5360mm
Width: 2010mm
Net Weight: 1920Kg
Packing: Packed with steel frame
Approval: CE
Features:
1). New design for lift left/right moving structure, using metal built in gears instead of chain, more steady and extend the working life.
2). New design for connection part between the carne part and the trailer, crane part can be take off from the machine , and Trailer length to be adjustable.
3). Improved grappler, using thickness steel plate instead of steel tube inside the grappler, avoid the broken of steel tube when grapping wood too tight.
4). Add Saftey Valve, ensure lift wood not fall down even without hydraulic.
5). Add Lift Arm rotary speed adjustable Valves, can adjust the Lift Arm rotary speed ensure high working efficiency.
6). With Quick Hydraulic Connectors, easy to connect to the Track hydraulic system.
7). Lift Arm Slewing angle to be expanded to 360 degree
