Hydraulic Power pack with Hydraulic Breaker, Honda Engine, New ProductHydraulic Power Station with Hydraulic Breaker
Model: CPH2101
Engine: Honda GX390, 4Stroke, Air Cooled, OHV, Single Cylinder
Engine Power: 13HP/3600rpm (9.6Kw/3600rpm)
Gasoline Tank Capacity: 6.5L
Lubricant : 1.1L
Fuel Consumption: 313g/Kwh
Hydraulic Oil Tank Capacity: 20L
Outlet Pressure: 140Bar
Max. Pressure: 210Bar
Max. Back Pressure: 17Bar
Flow: 25-30L/min
Axial cooling system: 4HP
Foldable handle and hose winding device
Incorporated oil level indicator and temperature gauge easy for regular inspection
With Hydraulic Hose and Hydraulic Breaker
Hydraulic Hose Length: 8m
With 2Pcs of Chisel (32*32*500mm)
Overall Size: 86*60*86cm
Weight: 150Kg (With Hydraulic Breaker)
125Kg (Without Hydraulic Breaker)
Hydraulic Breaker Data:
Weight : 25.2Kg (without hose and chisel)
Chisel adaptor hole: Hex 32*160mm
Flow: 18-30 l/min
Work pressure: 10.5-12.5Mpa
Max. back pressure: 1.5Mpa
Hydraulic Oil temperature: 30-70
Nitrogen chamber pressure: 5Mpa
Release valve pressure Max.: 16Mpa
Frequency: 19-31Hz(1140-1860 per min.)
Impact energy: 110J
Packing: Wooden Case, 1Pc/Ctn, GW/NW: 160/150Kg
Case Size: 90*90*90cm
