Automatic Stretch Film Wrap Machine

Specifications

1.CE
2.PLC control
3.Automatic feeding
4.Touch screen
5.Diameter: 1500-2000mm

Thank you for  visiting us ,it;s so luck to meet you







--------------------------------------------------------------------------------------------------------------------

About our  pallet wrapper machine :



1.Our machine use LLDPE stretch film as the main packing material to wrap the bulk cargos stacked on the pallet

2.Film provides extra support during transportation and storage to protect them from dust, moisture or damage

3.The stretch wrapping machine has been widely used in industries such as glassware, tools,  electric & electronic, paper,

pottery, food & beverage, et





--------------------------------------------------------------------------------------

pallet wrapper machine specification:





model	SM-1600
max packing hight	2000mm(can be customized)
max packing area	1300x1300mm
max packing weight	2000KG
turntable size	1500mm(can be customized)
turntable speed	0-14r/min
Working speed	30-40loads per hour
power supply	110V/220V/380V
control type	PLC
consumables	LLDPE
film width	500mm
ramp	optional
measuring hight	photoelectric sensor
turntable start mode	frequency conversion slow start
machine size	2600x1500x2400mm
weight	480KG
delivery time	15 working day
warranty	one year(free charge spare parts )
maintenance service	engineer help to slove any problem





--------------------------------------------------------------------------------------

  pallet wrap machine detail





  1.pallet wrapper machine control pannel one button start wrapping

     speed/pre-stretch rate /lift speed easy adjusted on the pannel







 2. SIEMENS frequency converter and famous brand electric parts





 3.Pre-stretch device ,pre-stretch film rate:250% save the film very much









 4.install the stretch wrapping machine



 5.packing and delivery stretch wrapping machine



Pallet wrapper machine features:



1. High efficiency and low electricity-consumption, convenient in operation.

2. The wrapping type and times can be designed on customers’ requirements.

3. photoelectric sensor test pallet height automatic

4. Auto reset of turn table

5. Pre-stretch ratio: 25~250% (adjustable).

6. SM-2517R with top press.

7. Programmable control and frequency converter is available.

8.PLC control ,manual optional. Wrap cycle (top, bottom, reinforcement) adjustment.

Variable lift speed/ film tension control. Film up/down controls.

9.pallet stretch wraping machine soft start and soft stop. 10.Suitable for heavy pallet

--------------------------------------------------------------------------------------
