Automatic Flaps Folding Carton Sealer With Factory Price

Automatic Flaps Folding Carton Sealer With Factory Price photo-1
Automatic Flaps Folding Carton Sealer With Factory Price photo-2
Automatic Flaps Folding Carton Sealer With Factory Price photo-3
Automatic Flaps Folding Carton Sealer With Factory Price photo-4
Automatic Flaps Folding Carton Sealer With Factory Price photo-5
US$ 800 - 2,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Beverage, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type Cartons
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 110V/220V
Power 0.4kw
Place of Origin Jiangsu, China
Brand Name automatic carton box sealer
Model Number RPC-07
Dimension(L*W*H) 2000x960x1580
Weight 150kgs
Certification CE ISO9001
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Application

Automatic flaps folding carton sealing machine,cutter, Sealing effect is more smooth, precise cutting with position, more solid .

SPECIFICATIONS FOR CARTON SEALING MACHINE
Carton size
L:200mm-600mm W:150mm-500mm L:120mm-500mm
Power suply
110/220V/50HZ
Table high
min:650mm max:800mm
Working speed
20ctns/min
tape width
48/60/75mm(alternative)
frame material
painting steel
pneumatic
5kg/cm2
adjust type
manual
cylinder
AIRTAC
Electric parts
OMRON
Blade
High speed steel
onput &output conveyor
0.5m
machine size
1700*900*1510(L*W*H)
machine weight
180KG

Customer site:Automatic packing line.

Automatic carton erector + conveyor + Automatic flaps folded carton sealing machine + carton corner sealing machine.

Detailed Images

Side belts drive and roller conveyor.

Side belts drive and roller conveyor make cartons through more smoothly.

Machine material.

Our machine material is more thick than traditional machines,more strong and durable.

Machine core.

On the basis of the introduction of foreign technology to design more stable equipment sealing machine, let the tape completely flat on the carton sealing position. High strength carbon steel have been assembled, more durable than traditional machine core institutions, more efficient!

Blade.

Blade material is high speed steel,Warning color blade protection cover for your safety operation.

Flaps folded device.

Folding flaps automatically,and this part was tested for more than 10 0000 times,very steady and durable.



Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
1800(L) * 900 (W) * 1450 (D)  (mm)
Weight
1.2 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
FAQ

1.How to adjust the machine to fit the cartons ?

You can adjust it by hand shank,there are three hand shank to adjust height and width for cartons.

2.How to adjust the machine's table height ?

The machine's table height is adjustable,some customer buy this machine for working in packing line,the machine need to be connected with conveyor,so our machine's leg  height is adjustable,like picture shows.

3.How to installate the tape roll?

Many customers are confused about installating the tape roll,so we tape a label on the machine,teach you how to installate it correctly.

Our Factory
You may like

Stainless steel flaps folded carton sealing machine

If your working enviroment is wet,you may Like this stainless steel carton sealing machine,for vegetables and fruits.

Automatic carton erector box forming machine

You still open your boxes by hands?

We have machine for openning and forming the boxes.

Semi-automatic carton sealing machine

If your daily output not too much,you can choose this semi-automatic machine,this machine's capacity is enough for you.
