Automatic Juice/Milk/Oil/Liquid/Mineral Water Pouch Packing Machine Price
- SHANGHAI GUANGZHOU
- T/T L/C D/P D/A Money Gram Credit Card
You May Like
-
Liquid Sachet Small Bag Packing Machine Price Malaysia
-
Magnetic Drive Pump Sachet Water Filling and Packing Machine
-
Angel Factory Sachet Water Filling Packing Machine/sachet Filling Machine/liquid Sachet Filling Machine
-
Vertical Machine Three Rollers Heat Sealed Milk Sachet/pouch Water Packing Machine
-
Double Rows Heat Sealed Sachet Water Packaging Machine
-
Automatic Sachet Liquid Packing Machine/small Sachets Shampoo Packing Machine/body Lotion Filling and Sealing Machine
Product Details
| Condition | New | Function | Embossing, Filling, Gluing, Sealing, Slitting | |
| Application | Beverage, Chemical, Commodity, Food, Medical | Packaging Type | Bags, Film, Pouch | |
| Packaging Material | Paper, Plastic | Automatic Grade | Automatic | |
| Driven Type | Electric | Voltage | 380V | |
| Power | 3.8 KW/AC | Place of Origin | Hubei, China | |
| Brand Name | Hi-Tech | Model Number | HT-Y319F-N/H | |
| Dimension(L*W*H) | L1400mm*W1000mm*H1800mm | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
double rows vertical type automatic high speed honey packing machine is a three roller vertical packaging machine designed for the implementation of the viscous or pasty fluid materials automatic packaging, can realize three edges sealing or four edges sealing packing.
The whole machine adopts the advanced industrial computer bus design and PLC control system, through the color touch screen to finish all kinds of parameter setting and modification, characteristic of the photoelectric control system can make photoelectric automatic calibration in 2-3 bag cursor position. The seals adopt roller method, solid and reliable. Packing materials injected into packing bags by Hibar pump, high precision, the cut off ways can use each of flat knife, serrated knife, point marking knife.And equipped with with ease open bags cutting device.
Technology parameter
Bag Size | Length: 50-210mm | Width: 30-150mm |
Packing Speed | 20-120 Bags/min | |
Capacity Range | 1-200ml | |
Bag Materials | PET/PE,PET/AV/PE, NY/AL/PE,NY/PE, etc | |
Mechanical Power | 3.8KW/AC 380V | |
Mechanical Dimensions | L1400mm*W1000mm*H1800mm | |
Sealing Method | Three or four edges sealing | |
Net Weight | 500Kg | |
Optional Device | Product conveying belt, Automatic feeding system, Liquid level display device, Mixing system, Third section electric control system, Code machine/Printing machine, Voltage regulator, Air compressor, Back suction device | |
Electronic parts
In our machine, there are lots of electronic parts, some of them come from chinese best manufacturers and some from japan, german. They have different function to make the whole machine running well, we making a simple list to show these parts.
Longitudinal sealing inverter: | 0.75KW Panasonic inverter |
Transverse sealing incerter: | 1.5KW Panasonic inverter |
Touch screen: | WeinView touch screen |
PLC Module: | Delta PLC |
Temperature Controller: | Omron |
AC contactor: | DELIXI |
Relays: | Omron |
Color logo recognition sensor: | BALEFU |
Angle encoder: | Seiko |
Circuit protector: | DELIXI |
Main Motor: | YUQIU |
Type 80 vertical gear reducer: | YUQIU |
Type 50 horizontal gear reducer: | YUQIU |
Solid state relays: | Tianhao |
Application & Sample
Our machine can be applied to following scope & products, include Food, Medicine, Pesticide or some other related liquid materials (As shown)
Processing
We have a group of Seasoned workers, their average age is 40 years old, and the chief engineer is Chinese first batch of personnel that engaged in design and manufacture of packaging machinery industry, our company also spends resources for the cultivation of young engineers. With them, we can promise you the high quality and best after-sale service. All our processing flows comply with related standards to ensure our products qualified leave factory, there are some pictures show the processing.
Packaging & Shipping
We use plywood case as the normal packaging case, if client or nation standard requires, we can offer fumigating wooden case too. Shipping by sea is the normal type and urgent by air.
After Sales Service
·Find our products through or http://hi-techmachinery.en.china.cn
· One year warranty for the whole machine
· Free equipment installation and debugging
·After one year, we can help you to maintain the machine and the accessories are provided omle one the cost price
·Every 3 years, we can help to overhaul the machine freely (labor)
·We can provide internship service and help you train the operator and machunic
·Free production technology and process configuration
Our Factory
Wuhan Hai Tai Wei Chuang Technology Co., Ltd. located in the Daijiashan Science&Technology Park of Wuhan city Since 2002. We have 13 years of production experience.Our company is one of the most professional vertical type small bag packing machine enterprises that integrate research and development,manufacturing of single packing machine & packing line. We has been devoting to the develop of domestic and international markets. It has dozens of distributors and after service outlets spreading around China, providing good pre-sales and after-sales services for the customers.
Looking forward to establishing good business relationship with you on mutual benefit!
Always welcome!
We have a group of Seasoned workers, their average age is 40 years old, and the chief engineer is Chinese first batch of personnel that engaged in design and manufacture of packaging machinery industry, our company also spends resources for the cultivation of young engineers. With them, we can promise you the high quality and best after-sale service.
The salemen in our company are excellent too, we often join Alibaba, Baidu, chamber of commerce and oher related organization's training and activity, our company also give us a lot of training about machine's knowledge, our goal is to be the team that can solve clients' questions at the first time.

Partners
In china, our company has a lot of partners, and cooperating with each other, we offer solution to partners as per their requirements, and they give us market popularity, each takes what he needs.
We also have some foreign partners in Australia, Russia, Brazil, East-south asia and etc.. Now we spend a lot of resources, want to develop more foreign partners, become a trustworthy outstanding supplier, get more market recognition.
The following picture shows our main partners logo.
