HT - HP series puffed food packinng machine is a new feeding model machine with exclusive design and development and has patented technical that made by Wuhan Hi-tech machinery Co., Ltd.,for the first time using the numerical control to adjust feeding measurement and accuracy, can realize online adjustment between 1-150g range, make the product packaging specifications frequently change is not complicated any more. The machine through the touch LCD screen, can easily and accurately complete adjustments for bag size, packing capacity, packing speed and automatic calibration function.Adjusting the bag length and number online, change specifications operation is simple, without other parts replacement, no material wear, no pollution materials.
1, High speed and high precision.
2, man-machine dialogue operation interface.
3, setting of bags length can simple and reliable adjustments in a wide-area.
4, photoelectric automatic calibration within three bags.
5, double variable frequency drive, stable and reliable running.
6, roller suppoted by high temperature bearing, perfect sealing, free maintenance, low noise
Bag Size | Length: 50-300mm | Width: 30-180mm |
Packing Speed | 20-60 Bags/min | |
Capacity Range | 5-150g | |
Bag Materials | PET/PE,PET/AV/PE, NY/AL/PE,NY/PE, etc | |
Mechanical Power | 3.8KW/AC 380V | |
Mechanical Dimensions | L2100mm*W950mm*H1850mm | |
Sealing Method | Pillow type | |
Net Weight | 250Kg | |
In our machine, there are lots of electronic parts, some of them come from chinese best manufacturers and some from japan, german. They have different functions to make the whole machine running well, we making a simple list to show these parts.
Parts Name | Model |
Main motor | IT8014 |
Displayer |
|
Actuator | 2H806 |
Solid-state relay | MGR-ID4810 |
Steping motor | YF-85BYG |
Reduction gear | PA-88-18 |
Air Switch | SCB2-63 |
Heater |
|
Temperature controller | YL-6SB |
Button switch | 2B2-BE101C |
Current plate | DZ2014ZLB |
Proximity switch |
|
Transformer |
|
Rotary switch |
|
Base frame | Stainless steel |
Hopper |
|
Our machine can be applied to following scope & products, include Food, Medicine, Pesticide or some other related materials (As shown)
We have a group of Seasoned workers, their average age is 40 years old, and the chief engineer is Chinese first batch of personnel that engaged in design and manufacture of packaging machinery industry, our company also spends resources for the cultivation of young engineers. With them, we can promise you the high quality and best after-sale service. All our processing flows comply with related standards to ensure our products qualified leave factory, there are some pictures show the processing.
We use plywood case as the normal packaging case, if client or nation standard requires, we can offer fumigating wooden case too. Shipping by sea is the normal type and urgent by air.
·Find our products through or http://hi-techmachinery.en.china.cn
· One year warranty for the whole machine
· Free equipment installation and debugging
·After one year, we can help you to maintain the machine and the accessories are provided omle one the cost price
·Every 3 years, we can help to overhaul the machine freely (labor)
·We can provide internship service and help you train the operator and machunic
·Free production technology and process configuration
Wuhan Hai Tai Wei Chuang Technology Co., Ltd. located in the Daijiashan Science&Technology Park of Wuhan city Since 2002. We have 13 years of production experience.Our company is one of the most professional vertical type small bag packing machine enterprises that integrate research and development,manufacturing of single packing machine & packing line. We has been devoting to the develop of domestic and international markets. It has dozens of distributors and after service outlets spreading around China, providing good pre-sales and after-sales services for the customers.
Looking forward to establishing good business relationship with you on mutual benefit!
Always welcome!
We have a group of Seasoned workers, their average age is 40 years old, and the chief engineer is Chinese first batch of personnel that engaged in design and manufacture of packaging machinery industry, our company also spends resources for the cultivation of young engineers. With them, we can promise you the high quality and best after-sale service.
The salemen in our company are excellent too, we often join Alibaba, Baidu, chamber of commerce and oher related organization's training and activity, our company also give us a lot of training about machine's knowledge, our goal is to be the team that can solve clients' questions at the first time.
Partners
In china, our company has a lot of partners, and cooperating with each other, we offer solution to partners as per their requirements, and they give us market popularity, each takes what he needs.
We also have some foreign partners in Australia, Russia, Brazil, East-south asia and etc.. Now we spend a lot of resources, want to develop more foreign partners, become a trustworthy outstanding supplier, get more market recognition.
The following picture shows our main partners logo.
