Scrap Steel Framework Baler &cutter Machine

Name: Scrap Steel Framework Baler &cutter Machine
Brand: gaode
SKU: 141042136
Availability: InStock

Jiangsu Gaode Hydraulic Machinery Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Other, scrap metal working over

Packaging Type:

Other, in nude

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai for crap steel framework baler &cutter

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, scrap metal working over

Packaging Type Other, in nude

Packaging Material Other, in nude

Automatic Grade Automatic

Driven Type Hydraulic

Voltage based on customer

Power 110 KW

Place of Origin Jiangsu, China

Brand Name gaode

Model Number HBS

Weight about 38000 kgs

Dimension(L*W*H) none

Certification ISO9001:2000

After-sales Service Provided Engineers available to service machinery overseas

Specifications

crap steel framework baler &cutter scrap,PLC
espical scrap car, vehicular
pre-compress and cut scrap
cut bars and profile

No.	crap steel framework baler &cutter Technical Specification					Remark
1	Press Box Size(LWH)			50001600900mm
2	Bale Size(LWH)			700*500mm
3	Hydraulic System Pressure			25 MPa
4	Total Motor			110KW
5	Power			380V/3PH,50Hz
6	Blade Length			800mm
7	Shearing Frequency (times/min)			3-5 time/min
8	Capacity(Ton/Hour)			4-12
9	Max Cutting Force (material Tensile Strength no more than 440MPa)			Round TeelΦ120mm
				Billet 110*110mm
				Steel Plate 50*600mm
10	Motor	Model	Y200L₂-6	Nominal Power	55KW
		Nominal Speed	970rmp	Quantity	2 pieces
11	Hydraulic Pump	Model	250YCY14-1B	Nominal Pressure	31.5MPa
		Nominal Outflow	250ml/r	Quantity	2 Pieces
12	Equipment Outline Dimension			1130028003500(Flank Expansion)		LWH
				1130022003500mm(Flank Collapsed)		LWH
13	Floor Space			14000*4000mm		L*W
14	Control System			PLC Automatic Control
15	Cooling System			Oil - steam heat exchanger

Applications:

HBS serieso of heavy-duty hydraulic shears are suitable for
compressing and cutting thin&light materials,production and
living scrap steel,light metal structural parts,plastic
non-ferrous metals (stainless steel,aluminium ulloy,copper,
aetc),or used to compress and bale the above mentioned
materials.

This machine is able to:
Pre-compress and cut scrap
Cut bars
Package light scrap
Squeeeze and cut car bodies
