Selling Car Baling Shear HBS Series in Worldwild Market

Name: Selling Car Baling Shear HBS Series in Worldwild Market
Brand: gaode
SKU: 141042116
Availability: InStock

Jiangsu Gaode Hydraulic Machinery Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Other, scrap metal working over

Packaging Type:

Other, in nude

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai for scrap car baling shear

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, scrap metal working over

Packaging Type Other, in nude

Packaging Material Other, in nude

Automatic Grade Automatic

Driven Type Hydraulic

Voltage base on customer

Power 110000 W

Place of Origin Jiangsu, China

Brand Name gaode

Model Number HBS

Weight about 40000 kgs

Dimension(L*W*H) none

Certification ISO9001:2000

After-sales Service Provided Engineers available to service machinery overseas

scrap car baling shear

1	Press Box Size(LWH)			50001600900mm
2	Bale Size(LWH)			700*500mm
3	Hydraulic System Pressure			25 MPa
4	Total Motor			110KW
5	Power			380V/3PH,50Hz
6	Blade Length			800mm
7	Shearing Frequency (times/min)			3-5 time/min
8	Capacity(Ton/Hour)			4-12
9	Max Cutting Force (material Tensile Strength no more than 440MPa)			Round TeelΦ120mm
				Billet 110*110mm
				Steel Plate 50*600mm
10	Motor	Model	Y200L₂-6	Nominal Power	55KW
		Nominal Speed	970rmp	Quantity	2 pieces
11	Hydraulic Pump	Model	250YCY14-1B	Nominal Pressure	31.5MPa
		Nominal Outflow	250ml/r	Quantity	2 Pieces
12	Equipment Outline Dimension			1130028003500(Flank Expansion)		LWH
				1130022003500mm(Flank Collapsed)		LWH
13	Floor Space			14000*4000mm		L*W
14	Control System			PLC Automatic Control
15	Cooling System			Oil - steam heat exchanger
