| cheap price cotton bale press for sale |
No. | TECHNICAL SPECIFICATIONS | REMARKS | |||||
1 | Nominal Force | 250KN | 25tons | ||||
3 | Press Box Size(L×W×H) | 1000×450×1000mm |
| ||||
4 | Bale Size (L×W×H) | 1000×450×(~1000)mm |
| ||||
5 | Control and Operation | Manual valve |
| ||||
6 | Bale Belting | Manual belting |
| ||||
7 | Bale Discharging | Push-out |
| ||||
8 | Hydraulic System Pressure | 12.5MPa |
| ||||
9 | Voltage | 380V/3PH |
| ||||
10 | Motor | Model | Y160L-4 | Quantity | 1set |
| |
Nominal Speed | 1460rpm | Nominal Power | 11KW |
| |||
11 | Hydraulic Pump | Model | CBA1050 | Quantity | 1set |
| |
Nominal Outflow | 50ml/r | Nominal Pressure | 20MPa | ||||
Applications :
HC82 series of loose material balers can press & pack loose materials like cotton yarn. Waste cotton, pieces of cloth, wool tops ,etc. The bales have larger density and uniform size, suitable for containerized transportation on, HC82 series are also applicable in compress scrap paper, plastic scraps, straw, metal cans & tins.
Features:
1) Baling force from 15 to 200 tons with a variety of models & specifications.
2) Hydraulic drive & top-mounted cylinder.
3) Imported seals used in cylinders to ensure quality & durable use
Gaode has fully testing equipment to ensure productivity and quality
Gaode has achieved CE,ISO,SGS approval. Also get 11 patents.
Gaode product will be tested in the factory line before packed.
Gaode product is strongerly fixed by steel wires when loading.
China famous trade mark
Thirteen years focused on Recycling Equipment.
Gaode equipment have export to more than 10 countries in Europe, the Middle East, Southeast Asia,Africa, South America and areas etc.
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
Q1:Can I add my logo on the machines?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for machines?
A:100% self-inspection before packing
Q4:Can I have a visit to your factory before the order?
A:Sure,welcome to visit our factory.
Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q5: Can we order one set machine?
A:Yes, you can.
Contact information:
Tracy
Skype: bellabest4
Sales representative
Jiangsu Gaode Hydraulic Machinery Co.,Ltd
China factory
ADD: No. 691 Chengshan Road, Jiangyin City, Jiangsu Province.
Tel: +86 15896491581(24 hours service) | Fax: +86 510 86993993
Our Finished Machine:
