Hydraulic Turn-out Scrap Metal Packing Machine
Applications
HC81 series of hydraulic metal balers are applicable in steel plants, recycling companies, ferrous &non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles) into acceptable furnace charges (shapes: Cuboid, cylinder or octagon), so as to reduce cost of transportation, to increase speed of furnace charging.
Features:
1, Hydraulic drive for all machine types, manual valve control or PLC control.
2, Bale-discharging: " turn-out", " push-out ", " forward-out" or manual discharging.
3, No footing bolts needed in installation; Diesel engine can be equipped for power.
4, Baling force 10 grades from 63 to 400 tons; Productivity from 4 to 40 tons per shift( 8 hours )
5, Press box size, bale size & bale shape can be customized.
1 | Hydraulic System Pressure | 25MPA (Bale-discharging 6MPA) |
| ||||
2 | Press Box Size | 1600*1000*800mm | L*W*H | ||||
3 | Bale Size | (~550)*400*400mm | L*W*H | ||||
4 | Cycle Length | App. 100 Sec |
| ||||
5 | Hydraulic Pump | Model | 160YCY14-1B | Quantity | 1 set |
| |
Nominal Outflow | 160ml/r | Nominal Pressure | 31.5MPA |
| |||
6 | Motor | Model | Y200L2-6 | Quantity | 1 set |
| |
Nominal Power | 22KW | Nominal Speed | 970rpm |
| |||
The Certificate
Welcome to Gaode
Guarantee and after-sale service
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
