Hydraulic Waste Metal Compress Baler With Close Door
Applications Of Hydraulic Waste Metal Compress Baler With Close Door:
HC81T-1600 hydraulic metal baler is applicable in steel plants, recycling companies, ferrous &non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles) into acceptable furnace charges (shapes: cuboid, cylinder or octagon), so as to reduce cost of transportation, to increase speed of furnace charging.
Features Of Hydraulic Waste Metal Compress Baler With Close Door:
1, Hydraulic drive , manual valve control or PLC control .
2, Bale-discharging:" turn-out".
3, No footing bolts needed in installation ; diesel engine can be equipped for power.
Technical Specifications Of Hydraulic Metal Baler:
Model | Nominal Force | Press box size (LXWxH) | Bale size (WXH) | Bale Density | Capacity | Cycle time | Power | Bale Discharging/ Operation |
(KN) | (MM) | (MM) | (KG/M3) | (KG/H) | (S) | (KW) | ||
HC81/F-1600 | 1600 | 1600X100X800 | (400-600)X350X350 | ≥1800 | 2000-3000 | 150 | 22 | Turn-out , manual valve control |
(400-600)X400X400 | ||||||||
HC81/T-1600A | 1600 | 1600X1000X800 | (400-600)X350X350 | ≥1800 | 2000-3000 | 150 | 22 | Push-out, manual valve control |
(400-600)X400X400 | ||||||||
HC81/T-1600B | 1600 | 1600X1200X800 | (400-600)X350X350 | ≥1800 | 2000-3000 | 160 | 30 | |
(400-600)X400X400 | ||||||||
HC81/F-2000 | 2000 | 1600X1200X800 | (400-700)X400X400 | ≥1800 | 2500-4000 | 160 | 30 or37 | Turn-out, manual valve control or PLC control |
HC81/F-2500 | 2500 | 2000X1400X900 | (400-700)X500X500 | ≥1800 | 3500-5000 | 160 | 44 | |
HC81/F-3150 | 3150 | 2000X1400X1200 | (450-700)X600X600 | ≥1800 | 3500-5000 | 160 | 60 | |
HC81/F-4000 | 4000 | 2600X1750X1200 | (500-1000)X650X650 | ≥1800 | 5000-6500 | 160 | 90 | |
HC81/F-5000 | 4000 | 2600X1750X1200 | (500-1000)X650X650 | ≥1800 | 9000-11500 | 160 | 90 | |
HC81/T-2000A | 2000 | 1600X1200X800 | (400-700)X400X400 | ≥1800 | 2500-4000 | 160 | 30 or37 | Push-out, manual valve control or PLC control |
HC81/T-2000B | 2000 | 1800X1400X900 | (400-700)X400X400 | ≥1800 | 2500-4500 | 160 | 30 or37 | |
HC81/T-2500A | 2500 | 2000X1400X900 | (400-700)X500X500 | ≥1800 | 3500-5000 | 160 | 44or60 | |
HC81/T-2500B | 2500 | 2000X1400X1200 | (450-800)X600X600 | ≥1800 | 3500-5000 | 160 | 60 | |
HC81/T-3150A | 3150 | 2000X1400X1200 | (450-700)X600X600 | ≥1800 | 3500-5000 | 160 | 60 | |
HC81/T-3150B | 3150 | 2600X1750X1200 | (450-800)X650X650 | ≥1800 | 4500-5000 | 160 | 90 | |
HC81/T-4000A | 4000 | 2600X1750X1200 | (500-1000)X650X650 | ≥1800 | 5000-6500 | 160 | 90 | |
HC81/T-4000B | 4000 | 3000X2000X1200 | (600-1100)X600X700 | ≥1800 | 6000-8500 | 160 | 110 |
The Production Flow:
GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane.
In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.Our company was first inaugurated in 2003.
Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.
Finished Products
Our Exhibition
Our Certification
Welcome To Our Factory
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
Ms. Apple Zhang
Sales representative
Jiangsu Gaode Hydraulic Machinery Co.,Ltd---China factory
Add: No. 691 Chengshan Road, Jiangyin City, Jiangsu Province.
Mobil/What's App : +86-15906169741 (24/7)
Tel: 86-510-86996082
Fax: 86-510-86993993
Skype: zhangguoping520
QQ: 445228997
Q1:Can I add my logo on the machines?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for machines?
A:100% self-inspection before packing
Q4:Can I have a visit to your factory before the order?
A:Sure,welcome to visit our factory.
Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q5: Can we order one set machine?
A:Yes, you can.
