Jiangsu Gaode Hydraulic Machinery Co., Ltd.: Jiangsu, China; Main products: Hydraulic Metal Shear HBS Scrap Baler & Shear, Q91Y Heavy Shear, Gantry Cutting Machine, Container Shear, Hydraulic Baler Scrap Metal Baler, Scrap Paper Baler, Car Baler, Scrap Shredder

Home > Products > Paper & Plastic Horizontal Baler > HPM Horizontal Manual Hay Strapping Waste Paper Baler

HPM Horizontal Manual Hay Strapping Waste Paper Baler

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Other, Machinery & Hardware, horizontal waste paper baler
Packaging Type	Other, horizontal waste paper baler	Packaging Material	Other, horizontal waste paper baler
Automatic Grade	Semi-Automatic	Driven Type	Hydraulic
Voltage	Customized	Power	30kw, 30KW
Place of Origin	Jiangsu, China	Brand Name	gaode
Model Number	HPM-1000, HPM-1000	Certification	ISO9001:2008
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

1.Packaging material: scrap paper & plastic scraps & straw
2.Horizontal structure
3.PLC control
4.Push-button operation

HPM Horizontal manual hay strapping waste paper baler

HPM series of horzontal balers with manual belting,applicable for
baling & belting of loose materials like scrap paper (cardboard,newspaper),plastic
scraps(PET bottle,plastic film or crates) & straw,etc.

Features:
1) Horizontal structure; Feeding can be manual or automatic with conveyor.
2) PLC control, push-button operation, safe & reliable.
3) Manual belting.

HPM-1000TECHNICAL SPECIFICATION

No.	Technical Specifications							REMARKS
1	Baling chamber dimensions(LWH)				4100×850×1000 mm
2	Feed opening size(L*W)				2300×1100 mm
3	Bale dimension(LWH)				(~1600)×850×1000 mm
4	Compacted density				≥400 kg/m³
5	Hydraulic System Pressure				21.5Mpa
6	Weight per bale				About 600 KG
7	Power Standard				380V/3PH,50Hz or as customer’s requirement
8	Total Power				29.5 KW
9	Main Motor	Model		Y200L2-6		Quantity	1 set
		Nominal Speed		980 rpm		Power	22 kw/380V
10	Hydraulic Pump	Model		160YCY14-1B		Quantity	1set
		Nominal Outflow		160 ml/r		Nominal Force	31.5MPa
12	Motor	Model		Y132S-4 /Y802-4		Quantity	1set
		Nominal Speed		1440rpm/1390rpm		Power	5.5KW/5.5HP
13	Capacity				4000-5000 kg/h
14	Conveyer Belt Specifications		width		1600 mm
			length		12000 mm
			speed		36m/min
15	Operation Method				Push-button
16	Belting Method				Manual belting with 5 ferrous wire

The Authentication Certificate

Welcome to Gaode

2013 ISRI Exhibition

Contact Information:

Suke

Jiangsu Gaode Hydraulic Machinery Co.,Ltd

Trademanager: cn1000682768

Tel:86-510-86996082

Fax:86-510-86993993

Mobile: 86 15251557803

Website: /enzhuye.asp
