Highway Guardrail hydraulic pile driving machine
- qingdao shenzhen shanghai tianjin
- T/T L/C D/P D/A Credit Card
You May Like
-
Low Consumption borings machine drill pile driver
-
High quality bore piling machine
-
China coal new design Hydraulic bore Hydraulic Pile Driver
-
Factory direct sale crawler hydraulic drilling rig piling machine
-
Screw pile driver machine manufacturer
-
Vibrating hydraulic post driver piling machine from China coal
Product Details
| Condition | New | Efficiency | High Efficiency | |
| Piling Speed(m/min) | 6m/min | Place of Origin | Shandong, China | |
| Brand Name | China coal | Model Number | ZM-360 | |
| Weight | 7200 | Dimension(L*W*H) | 7300x2100x2850 | |
| Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Introduction of pile driving machine
Piling speed, an average of 3 minutes to achieve piling 6 meters deep, that is, 3 minutes to play a hole.
Oil province, is the ordinary piling machine with about half the amount of oil, one year you can leave a piling machine money.
The drill bit is made of manganese steel and has been specially processed for a variety of geological environments.
Crawler walking, walking and climbing ability.
The frame can be moved back and forth, the drill bit can be adjusted around, piling positioning accuracy.
Main Parameter of pile driving machine
Bore diameter(DTH hammer)(mm) | 90-300 |
Bore depth(m) | 20-100 |
Air consumption(m³/min) | 10-26 |
Air pressure(Mpa) | 0.7-1.6(medium);1.6-2.46(high) |
Pipe diameter(mm) | 76/89 |
For rock(F) | 6-20 |
Bore diameter(screw)(mm) | Max 400 |
Bore depth(m) | 0-30 |
Screw pipe diameter(mm) | 130-400 |
Once promotion(mm) | 3200 |
Skid pitch(°) | 120 |
Swinging angle of skid(°) | Left and right total 40 |
Boom swing angle(°) | Left and right total 50 |
Rotation speed(r/min) | 0-110 |
Host power(kw) | 84 |
Climb ability(°) | 35 |
Dimension(L*W*H)(mm) | 5300*1950*2580 |
Weight(kg) | 5800 |
Walk speed(km/h) | 0-2.5 |
Figure Images of pile driving machine
