ZBLR630A Metal Concrete Rebar Locator Introduction
ZBLR630A Metal Concrete Rebar Locator
1.Multi function rebar detector = rebar locator + rebar corrosion detector; an economical and convenient device.
2.This model ZBLR630A Metal Concrete Rebar Locator features the world’s first wireless onsite data transfer function for such a device and remote management is also available
3.Data can be stored on a usb-thumb drive, great for field work
4.This device can generate rebar distribution map and rebar corrosion potential contour graph.
5.Powerful professional analysis-process software allows for the automatic generation of test reports .
ZBLR630A Metal Concrete Rebar Locator Main Parameter
Applicable range |
6mm~50mm |
Corrosion detection method |
Single electrode |
Double electrode |
||
Protective layer thickness range (mm) |
First range |
Second range |
Measuring range |
±1000mV |
0~1000 mV |
|
3~98 |
3~200 |
Accuracy |
±1mV |
±1mV |
||
Maximum allowed error for protective layer |
±1 mm |
6~59 |
10~79 |
Tested points Interval X |
0~100 adjustable |
20 fixed, |
±2 mm |
60~69 |
80~119 |
Tested points interval Y |
0~100 adjustable |
0~100 adjustable |
|
±4 mm |
70~90 |
120~200 |
Power |
Built-in chargeable lithium battery |
||
Maximum allowed error for diameters measurement |
±1 rebar standard level |
Battery Time |
>40 hours |
|||
Data transmission |
wireless transmission |
Dimensions |
212mm´134mm´50mm |
|||
USB port |
thumb drive storage available |
Weight |
0.9kg |
|||
ZBLR630A Metal Concrete Rebar Locator Figure Photos
