Introduction of pile hammer
pile driver / pile driving rigs / pile drilling machine / pile hammer
Pile diameter of 70mm – 800mm, the piling depth can reach 1 meters to 3 meters, the machine is equipped with automatic hydraulic shoveling casing, can be moving with before and after stretching, and is equipped with hydraulic direction.
The machine can self-generating electricity and external power supply,go for the construction,highways,power facilities,and solar photovoltaic generation.The machine has the features of quick positioning, pile pulling quickly,high efficiency, etc.
Main Parameter of pile hammer
Dimension (mm) | 4500*2000*2700 |
Total weight (kg) | 5500 |
Drilling depth (m) | 1-3 |
Drilling diameter (mm) | 70-800 |
Traveling speed (km/h) | 5-10 |
Gear pump model | 40/40 |
Hydraulic system working pressure (mpa) | 20-25 |
Hydraulic system displacement (ml/r) | 40/40 |
Power head torque (N.M) | 4800 |
Figure Images of pile hammer
