Specifications
plastic shredder and crusher1. High capacity
2. working stably
3. Low energy consumption
4. easy operation and lower price
High output plastic shredder and crusher two in one machine / waste plastic shredder crusher / plastic crushing machine with low consumption and low noise
plastic shredder used to crush big volume plastic stuff, such as: plastic container, fruit basket, film roll,wood and so on
plastic shredder adopts two stage crushing: first shredding, second crushing, this system can directly crush plastic container, fruit basket, plastic drum or wood into small particles with size< 10mm
As on option, you can also choose to buy one metal detector which can detect out the metal stuff contained in the materials, it can effectively protect blades of shredder and crusher
The single shaft shredder can shred PET bottle, PE,PP materials, waste plastic, plastic pipe and so on.
Well-design and easy to operate, high effecience, low temperature.
It is mainly used to crush various big solid material, unmanageable material, plastic container and barrel, plastic film, plastic pipe, fiber and paper which the normal crusher can not handle.
Main parameter of plastic shredder and crusher
Technical Data for single shaft shredder
|
Technical parameter
|
WT300 |
WT400 |
WT500 |
WT600 |
WT800 |
WT1000 |
WT1250 |
|
Quantity of rotary blades
|
22pcs |
20pcs |
24pcs |
28pcs |
46pcs |
64pcs |
72pcs |
Quantity of fixed blades |
2pcs |
2pcs |
2pcs |
4pcs |
4pcs |
4pcs |
4pcs |
Size of feeding mouth(mm) |
300X300 |
400X400 |
500X500 |
600*800 |
800×800 |
1000×1000 |
1250×1250 |
|
Diameter of rotation(mm)
|
150 |
220 |
220 |
220 |
400 |
400 |
500 |
|
Speed ( r/min)
|
80-100 |
80-100 |
80-100 |
80-100 |
80-100 |
80-100 |
80-100 |
|
Motor power (kW)
|
4 |
11 |
15 |
18.5 |
37 |
45 |
75 |
Hydraulic pressure power(KW) |
0.75 |
0.75 |
2.2 |
2.2 |
2.2 |
3 |
4 |
|
Size of the screener (mm)
|
22 |
22 |
22 |
22 |
22 |
22 |
22 |
|
Weight (kg)
|
300 |
1100 |
1100 |
2200 |
3100 |
4500 |
7000 |
Motor protection standard |
IP44 |
IP44 |
IP44 |
TP44 |
TP44 |
TP44 |
TP44 |
|
Noise (decibel)
|
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
≤75 |
Technical Data for double shaft shredder
| Model | LGSZ3280 | LGSZ32100 | LGSZ32120 |
| A (mm) | 3370 | 3880 | 3680 |
| B (mm) | 1400 | 1400 | 1990 |
| C (mm) | 804 | 1004 | 1204 |
| D (mm) | 510 | 510 | 776 |
| E (mm) | 850 | 1050 | 1410 |
| H (mm) | 2340 | 2370 | 2270 |
| Rotor Diameter (mm) | φ430 | φ430 | φ430 |
| Main Shaft Speed (r/min) | 15 | 15 | 15 |
| Rotate Blade Quantity (pcs) | 20 | 25 | 25 |
| Thickness of Blade (mm) | 40 | 40 | 40 |
| Main Motor Power (kw) | 15+15 | 18.5+18.5 | 22+22 |
| Weight (kg) | 4600 | 5400 | 7000 |
| We can design the machine according to your needs. | |||
Photos of plastic shredder and crusher
