soft pipes winder/winding machine
- 5 Set / Sets per Month
- shanghai
- T/T D/P D/A
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | sevenstars | Model Number: | winder |
Condition: | New |
Product Description
Specifications
1.for soft pipes ,sheets,films ect.2.easy to operate and clean
3.high quality and reasonable price
1.Plastic Pipe Winder
2.automatic
3.mainly used for the packing of the plastic soft pipings.
Plastic Pipe Winder;double disk winder
Performance and features:
1. This plane is mainly applied to aluminum-plastic composite pipe, the jacket line, PE pipe rolling, it can be extruder, gutters, ink pad printing machines, such as traction to form a well-set production lines. The machines reel breakdown rack sides were installed in the use of two or reel spindle on the electromagnetic clutch of the two winding turn, and in the intermittent time in the discharge, with the continuity of the production, winding neat features.
2. Main technical standards
Winder Disk NO. | 2 |
Winder Disk Inner Diameter (mm) | ¢540~¢1600 |
Largest Winding Diameter (mm) | ¢2100 |
Winding Width (mm) | 350 ~ 400 |
Spindle Speed (double speed) | 11rpm (max) / 130 rpm (max) |
Largest Winding Size | 63 |
Torque motor | 10N.m/25 N.m |
Wire | Wire Rod (0-70 ) |
Discharge | Pneumatic necking |
Air pressure | 0.6Mpa |
Dimensions | L3600 × W2600 × H2610 |
