Home > Products > PPR/PE pipe extrusion line > Plastic PE PPR Cold and Hot Water Supply Pipe Extrusion Machine Production Line
Plastic PE PPR Cold and Hot Water Supply Pipe Extrusion Machine Production Line
- 100 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- CNC router for stone processing engraving machine
- Glass polishing machine JMB95A
- Aluminum Profile Bending Machine/Arc Bending Machine for Aluminum
- Automatic aluminum window corner connector cutting machine
- aluminum door and window frame cutting machine aluminum windows and doors machine
- Upvc Window Door Machine Four Head Welding Machine for PVC welding Window Machine
Product Details
Condition: | New | Type: | Pipe Production Line | Pipe Material: | PE |
Application: | Other, Energy Supply Pipe, pe pipe production line | Production Capacity: | 16-630mm | Place of Origin: | Jiangsu, China |
Brand Name: | Horserider Machinery | Model Number: | SJ | Voltage: | 380V50HZ |
Power(W): | 37KW-90KW | Dimension(L*W*H): | 6*2.2*1.6m | Weight: | 6.5T |
Certification: | CE ISO | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
water supplying pe plastic pipe production line
Main Technical Data:
Model | RMSG-65/30 | RMSG-90/30 | RMSG-120/30 | RMSG-150/30 | RMSG-120/33 | RMSG-150/33 |
Pipe Size/mm | 16-63 | 75-160 | 160-315 | 200-450 | 315-630 | 400-800 |
Screw Diameter/mm | 65 | 90 | 120 | 150 | 150 | 150 |
L/D | 30:1 | 30:1 | 30:1 | 33:1 | 33:1 |
|
Capacity/kg/h | 80-160 | 180-220 | 250-400 | 500-600 | 700-900 | 800-1000 |
Hauling Speed/m/min | 0-16 | 0-10 | 0-6 | 0-3 | 0-2 | 0-1.5 |
Cutting Means | Saw blade or non-scrap cutting | Planetary cutting | Planetary cutting | Planetary cutting | Planetary cutting |
1.Extruder adopts big L/D and multi mixing structure, which is more suitable for the PE low temperature extrusion production.
2.Specially-designed spiral moulds for PE pipes, with inside oil controlling temperature system.
3.Beautiful and practical stainless steel body for the vacuum calibration and spray cooling system, unique multi-section vacuum system ensures the stable sizing and cooling for pipes; special spray cooling system improves the cooling efficiency ; special water position, water temperature system make the machine more intelligent.
4.Hauling-off unit adopts particular pedrail structure, which is easy and convenient for operation; pedrail clamping uses mechanical and pneumatic combining system, which is more reliable.
5.Cutting system adopts saw blades and planetary cutting means; sumping uses hydraulic system , which ensures the smooth cross section; equipped with dust-collecting unit, which ensures the clean working environment.
key words
PE PP PPR Pipe Production /Making/Extrusion Line (passed ISO9001:2000 and CE certificate)
PE pipe production line
Water and gas supply PE pipe production line
PE Pipe Production Line/Pipe Making Machine/Plastic
gas/water supply PE pipe extrusion line
pe pipe extrusion line/plastic machinery
PE Pipe Extrusion Line(plastic machine)
Best price of PE Pipe machine/PE pipe Extrusion Line
plastic pipe machine / pipe making machine
